Vishay Single Layer Ceramic Capacitor 10 nF 15 kV DC Screw Terminal Y5U Dielectric 715C15DKS10

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single Layer Ceramic Capacitor 10 nF 15 kV DC Screw Terminal Y5U Dielectric 715C15DKS10

Name: Vishay Single Layer Ceramic Capacitor 10 nF 15 kV DC Screw Terminal Y5U Dielectric 715C15DKS10
Brand: Vishay
SKU: 200915



Category Single Layer Ceramic Capacitors Brand Vishay Condition New

Specifications

Country of Origin	Germany
Voltage	15kV dc
Diameter	45.7mm
Brand	Vishay
Height	22.9mm
Model	715C15DKS10
Packaging	Bulk
Mount Type	Screw
Series	715C
Maximum Operating Temperature	85°C
Tolerance	-20 to 80 %
Capacitance	10nF
Minimum Operating Temperature	-30°C
Terminal type	Screw
Dissipation Factor	0.02%
Standards/Approvals	IEC 61249-2-21, EC, RoHS
Package/Case	0814
Pin Count	2
Dielectric	Y5U
Suppression Class	Class II

Key Features

High voltage rating suitable for applications up to 15 kV DC.
Capacitance value of 10 nF with tolerance from -20% to +80%.
Operates at a maximum temperature of 85°C.
Constructed with Y5U dielectric providing defined temperature characteristics.
Epoxy coated ceramic disc with screw terminal for robust mounting.
Diameter of 45.7 mm and height of 22.9 mm ensuring compact size.
Low dissipation factor of 0.02% for efficient performance.
Meets IEC 61249-2-21, EC, and RoHS standards.

Product Description

Vishay 715C15DKS10 is a high-voltage single layer ceramic capacitor designed for demanding electronic applications requiring stable capacitance up to 15 kV DC. It features a screw terminal mount for secure and dependable connection. This capacitor uses Y5U dielectric material, which provides a capacitance of 10 nF with a tolerance between -20% and +80%, suitable for various industrial environments.

The capacitor's epoxy coating offers protection against environmental influences, and its compact physical dimensions of 45.7 mm diameter and 22.9 mm height make it adaptable for diverse assemblies. It operates safely up to a maximum temperature of 85°C while maintaining a low dissipation factor of 0.02%, ensuring minimal energy loss during operation.

Certified to IEC 61249-2-21 standards and compliant with EC and RoHS directives, this component is ideal for industrial applications such as high-voltage power supplies, X-ray equipment, welding machinery, and CO2 laser systems. Its robust design and electrical characteristics enable reliable suppression of voltage transients and noise.

High voltage rating suitable for applications up to 15 kV DC. Capacitance value of 10 nF with tolerance from -20% to +80%. Operates at maximum temperature of 85°C. Y5U dielectric for stable performance in varying temperature ranges.

Screw terminal mounting provides secure mechanical and electrical connection. Compact size with 45.7 mm diameter and 22.9 mm height. Low dissipation factor of 0.02% for energy efficiency. Meets IEC 61249-2-21, EC, and RoHS compliance standards.

Applications include high-voltage power supplies, X-ray machines, welding, and CO2 lasers.

This capacitor is manufactured in Germany, assuring high-quality standards and consistency. Vishay's 715C series capacitors are renowned for their reliability in industrial and laboratory environments requiring precise and stable performance. Browse more capacitors and electronic components at EnvMart to suit your industrial and electrical needs.
