Vishay Single Layer Ceramic Capacitor 2 nF 40kV DC ±20% N4700 Dielectric Screw Mount 85 °C Max Op. Temp. 715C40KTD20
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 40kV dc |
| Diameter | 60mm |
| Brand | Vishay |
| Height | 31mm |
| Model | 715C40KTD20 |
| Mount Type | Screw |
| Series | 715C |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±20 % |
| Capacitance | 2nF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Dissipation Factor | 0.02% |
| Standards/Approvals | IEC 61249-2-21, EC, RoHS |
| Package/Case | 0814 |
| Dielectric | N4700 |
| Suppression Class | Class I |
Key Features
- Utilizes N4700 dielectric for stable Class I performance.
- Screw terminal mounting ensures secure electrical connection.
- Capacitance tolerance of ±20% for design flexibility.
- Operates reliably from -30°C to a maximum of 85°C.
- Features low dissipation factor of 0.02% at 1 kHz frequency.
- Complies with IEC 61249-2-21, EC, and RoHS standards.
- Constructed with epoxy coating and negligible piezoelectric effect.
- Manufactured in Germany ensuring quality and reliability.
Product Description
Vishay 715C40KTD20 single layer ceramic capacitor offers 2 nF capacitance and a high 40 kV DC voltage rating, ideal for industrial, high-voltage electronic applications. It features the N4700 dielectric material, providing Class I performance with high insulation resistance and very low dissipation factor of 0.02% at 1 kHz. The capacitor is mounted using a screw terminal, offering secure and reliable connections in power and control circuits.
Designed to operate over a broad temperature range, this capacitor functions between -30°C minimum and 85°C maximum operating temperatures, ensuring robust performance in harsh environments. Its epoxy coating enhances durability and environmental protection while minimizing piezoelectric and electrostrictive effects, important for signal integrity in sensitive electronics.
The unit measures 60 mm in diameter and 31 mm in height, suitable for mounting in various assemblies requiring single layer ceramic capacitors with high voltage withstand capability. This component complies with IEC 61249-2-21, EC directives, and RoHS requirements, reinforcing environmental and safety standards compliance.
Applications include power conditioning, high voltage pulse circuits, and filtering in industrial manufacturing, laboratory equipment, and electronic instrumentation. Its reliable performance makes it suitable for use in automotive electronics where high voltage stability is necessary despite automotive standards not being specifically claimed.
Utilizes high-quality N4700 strontium-based ceramic dielectric. Low inductance and high insulation for high power applications. Screw terminal mounting for practice-friendly installation. Stable capacitance with ±20% tolerance.
Class I suppression character for precise applications. Epoxy coating protects against environmental factors. Meets international standards including IEC and RoHS. Manufactured in Germany for assured quality.
Explore the Vishay series of Single Layer Ceramic Capacitors on EnvMart to find compatible high-voltage capacitors and related electronic components for your industrial and laboratory projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay 715C40KTD20 capacitor has a voltage rating of 40 kV DC.
This model has a capacitance value of 2 nF.
The maximum operating temperature for this capacitor is 85°C.
It utilizes the N4700 dielectric material, which provides stable Class I performance.
The capacitor has a diameter of 60 mm and a height of 31 mm.
The capacitance tolerance is ±20%.
This unit is mounted using a screw terminal, ensuring a secure electrical connection.
The dissipation factor is 0.02% at 1 kHz frequency.
It complies with IEC 61249-2-21, EC directives, and RoHS requirements.
The minimum operating temperature is -30°C.
It is suitable for applications such as power conditioning, high voltage pulse circuits, and filtering in industrial and laboratory equipment.
This capacitor is manufactured in Germany.
