Molex KK 396 Series Straight Through Hole Pin Header, 11 Contacts, 3.96 mm Pitch, 1 Row, Unshrouded, 7A 250V 26-60-4110

Molex 26-60-4110 KK 396 Series Straight Through Hole Pin Header is a high-quality wire-to-board connector designed for industrial and electronic applications requiring robust and reliable connections. Featuring 11 male contacts spaced at a 3.96 mm pitch in a single row, this header enables efficient signal or power transmission in circuit boards.

The header is constructed with brass contacts plated in tin to enhance corrosion resistance and electrical conductivity. The polyester housing provides excellent insulation and mechanical durability suitable for various operating conditions. Its unshrouded, straight orientation design facilitates easy visual inspection and soldering during manufacturing or repair processes.

This pin header supports a current rating of 7A and a voltage rating of 250V, making it suitable for moderate power applications. It is designed for through-hole mounting on PCBs and employs a solder termination type for secure mechanical and electrical connections.

Operating temperature ranges from -40°C to 80°C ensure performance stability in different environmental conditions encountered in industrial, electronics manufacturing, and repair settings. The product mates with a variety of Molex KK series housings and connectors, offering flexibility for system design.

Compact 11-contact pin header designed for reliable connections. 3.96 mm pitch ensures compatibility with standard PCB Headers. Unshrouded design allows easy inspection and soldering access. Constructed with brass contacts plated with tin for corrosion resistance.

Rated for 7A current and 250V voltage for robust performance. Polyester housing material offers durability and electrical insulation. Through-hole mount type suits PCB insertion and soldering requirements. Operates reliably from -40°C to 80°C across temperature extremes.

Straight orientation and solder termination type for standard assembly.

This Molex KK 396 Series pin header is ideal for use in industrial electronics, manufacturing, control systems, and laboratory equipment where dependable wire-to-board connections are required. The design supports increased production efficiency by enabling easy assembly and inspection. For additional connectivity options, compatible Molex housings and connectors are available to complement this pin header.
