Molex KK 254 Series Right Angle Through Hole Pin Header 5 Contact 2.54mm Pitch 1 Row Unshrouded 22-12-2054
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- Constructed with brass contacts plated in gold for superior conductivity.
- Features a nylon housing that is UL 94V-0 white rated for excellent flame resistance.
- Designed for right angle orientation with through-hole mount style ensuring secure PCB connections.
- Supports a maximum current rating of 4A and voltage rating of 250V.
- Operates reliably in temperatures ranging from -40°C up to 80°C.
- Termination type is solder, with male contact gender for wire-to-board connector systems.
- Unshrouded style enables easy mating with compatible connectors.
- Offers 2.54 mm row pitch and 1 row layout for compact PCB header design.
Product Description
Molex 22-12-2054 KK 254 Series Right Angle Through Hole Pin Header is an electronic connector component designed for precision PCB mounting applications. It features 5 gold-plated brass contacts arranged in a single row with a 2.54 mm pitch, providing excellent electrical performance for signal and power transmission.
The connector is manufactured with a high-quality nylon housing rated UL 94V-0, ensuring flame retardance and mechanical durability. Its right-angle orientation with through-hole mounting allows for robust and reliable board connections in compact electronic assemblies.
The device supports a maximum operating current of 4 amps and a voltage rating of 250 volts, suitable for many power and signal circuits within industrial, manufacturing, and electronic equipment environments. It can operate effectively across a temperature range spanning from -40°C to 80°C, ensuring stability in a variety of conditions.
The pin header is unshrouded and compatible with 2695 Series housings with friction lock functionality, facilitating easy mating and secure connections in wire-to-board applications. The termination type is solder, ensuring a firm bond on PCBs during assembly processes.
This component is ideal for use in industrial electronics, HVAC systems, manufacturing automation, laboratory instruments, and commercial equipment that require dependable and compact PCB connectors.
Constructed with brass contacts plated in gold for superior conductivity. Features a nylon housing that is UL 94V-0 white rated for excellent flame resistance. Designed for right angle orientation with through-hole mount style ensuring secure PCB connections.
Supports a maximum current rating of 4A and voltage rating of 250V. Operates reliably in temperatures ranging from -40°C up to 80°C. Termination type is solder, with male contact gender for wire-to-board connector systems.
Unshrouded style enables easy mating with compatible connectors. Offers 2.54 mm row pitch and 1 row layout for compact PCB header design. Explore Molex connectors across EnvMart for advanced PCB header solutions fulfilling various industrial and electronic design requirements.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this pin header is 4A.
This pin header has a voltage rating of 250V.
The pitch for this connector is 2.54 mm.
It operates reliably in temperatures ranging from -40°C to 80°C.
This model uses a solder termination type.
The pin header features 5 contacts.
The housing is made from nylon, which is rated UL 94V-0 for flame resistance.
This pin header is unshrouded, enabling easy mating with compatible connectors.
The orientation of this pin header is right angle.
It supports a wire-to-board connector system.
This pin header is manufactured in India.
The contacts in this pin header are male.
