Molex KK 254 Series Right Angle Through Hole Pin Header, 10 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-3101
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.58mm |
Key Features
- The connector supports a current rating of 4A for reliable electrical performance.
- Constructed with a nylon housing rated UL 94V-0 for fire resistance and durability.
- The brass contacts are tin plated ensuring corrosion resistance and good conductivity.
- Designed for right-angle orientation and through-hole mounting on PCBs.
- Operates reliably under temperatures ranging from -40°C to 105°C.
- Features a tail pin length of 3.58 mm for secure solder connections.
- Compatible with 2695 Series Housings with Lock for versatile assembly options.
- End-to-end stacking capability allows modular and expandable designs.
Product Description
Molex 22-05-3101 KK 254 Series Right Angle Through Hole Pin Header is a high-quality electronic connector designed for use in PCB board assemblies requiring reliable wire-to-board connections. Featuring 10 male contacts arranged in a single row with a 2.54 mm pitch, this unshrouded header offers efficient signal transmission and secure mating with corresponding housings.
The housing is made from white nylon UL 94V-0 material, providing excellent flame retardant properties and high mechanical strength. Brass contacts with tin plating ensure optimal electrical conductivity and resistance against corrosion, enhancing durability in industrial, commercial, and laboratory environments.
Designed for right-angle mounting, the connector facilitates space-saving layouts on PCBs and offers ease of installation through through-hole mounting. The tail pin length of 3.58 mm supports strong solder joints, ensuring robust electrical and mechanical connections under various operating conditions.
With an operating temperature range from -40°C to 105°C and current rating of 4A at 250V, this header performs reliably in diverse applications including manufacturing automation, electronic instrumentation, and power connectors. It also supports friction lock features for secure engagement and end-to-end stacking to enable scalable configurations.
The connector is fully compatible with Molex 2695 Series Housings with Lock, providing modular assembly options. Unshrouded design allows for ease of visual inspection and soldering. Ideal for industrial, laboratory, electronic component manufacturing, and HVAC control systems.
Offers excellent mechanical stability and corrosion resistance for enhanced product lifecycle.
This Molex KK 254 Pin Header is supplied as a new product from a trusted brand, optimized for reliable and safe electronic connectivity solutions. Explore more Molex connectors and PCB Headers at EnvMart for your electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header supports a current rating of 4A at 250V, ensuring reliable electrical performance.
This model features a contact pitch of 2.54 mm, suitable for various PCB applications.
The maximum operating temperature for this connector is 105°C, allowing it to function in a wide range of environments.
The housing is constructed from nylon rated UL 94V-0, providing fire resistance and mechanical strength.
This pin header has 10 male contacts arranged in a single row.
The tail pin length is 3.58 mm, which supports strong solder connections.
Yes, this model is designed for through-hole mounting on PCBs, facilitating easy installation.
This connector uses solder termination, ensuring robust electrical connections.
It is compatible with Molex 2695 Series Housings with Lock, allowing for versatile assembly options.
The minimum operating temperature for this connector is -40°C, making it suitable for various applications.
This pin header belongs to the wire-to-board connector system, designed for reliable connections between wires and PCBs.
