onsemi CMOS Inverter 6 Elements TTL Input Surface Mount 14-Pin SOIC 4.5-5.5V 74ACT04SCX

Free Delivery in India | Lowest Global Shipping Charges

onsemi CMOS Inverter 6 Elements TTL Input Surface Mount 14-Pin SOIC 4.5-5.5V 74ACT04SCX

Name: onsemi CMOS Inverter 6 Elements TTL Input Surface Mount 14-Pin SOIC 4.5-5.5V 74ACT04SCX
Brand: onsemi
SKU: 207645
Price: 0.22 USD
Availability: InStock



Category Inverters ICs Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	8.75mm
Model	74ACT04SCX
Width	4mm
Mount Type	Surface
Compatibility	Input TTL, Output CMOS
Series	74ACT04
Input Type	TTL
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Pin Count	14
Number of Elements per Chip	6
Maximum Supply Voltage	5.5V
Logic Family	ACT
Logic Function	Inverter
Minimum Supply Voltage	4.5V
Maximum High Level Output Current	-24mA
Maximum Propagation Delay Time @ CL	9ns
Maximum Low Level Output Current	24mA

Key Features

This inverter IC features 6 independent elements per chip, ideal for complex logic circuits.
It supports input TTL and output CMOS compatibility, enhancing versatility in digital circuits.
Designed with a maximum propagation delay time of 9ns at load capacitance, ensuring fast response.
Output current capabilities include maximum high-level of -24mA and low-level of 24mA.
Operates reliably within a temperature range from -40°C to +85°C for industrial applications.
Encapsulated in a 14-pin SOIC package measuring 8.75mm by 4mm by 1.5mm for compact PCB designs.
This device belongs to the 74ACT04 series, implementing advanced CMOS logic technology.
Surface mounting enhances assembly efficiency and component density on circuit boards.

Product Description

onsemi 74ACT04SCX CMOS Inverter is a 6-element logic IC designed for applications requiring TTL input and CMOS output compatibility. Operating voltage ranges from 4.5V to 5.5V, this 14-pin SOIC packaged device is surface mountable and compact with dimensions of 8.75mm length, 4mm width, and 1.5mm height. It delivers high-speed performance with a maximum propagation delay of 9 nanoseconds, making it suitable for industrial, laboratory, and electronic manufacturing environments.

This inverter IC provides a maximum high-level output current of -24mA and maximum low-level output current of 24mA, supporting reliable switching operations. The device functions well within an operating temperature from -40°C to 85°C, ensuring durability in harsh environments. It does not include Schmitt trigger input functionality but is fully compatible with standard logic families in digital designs.

Featuring 6 inverter elements per chip, this 74ACT04 family device is widely used in logic circuits for inversion tasks and signal conditioning in semiconductor applications. The SOIC package type is preferred for surface mounting on PCBs, enabling efficient circuit layout and heat dissipation.

This IC supports a TTL input with CMOS output compatibility. Built using Fairchild Semiconductor's advanced CMOS logic technology within the 74ACT series. Ideal for integration in various electronics including power and distribution systems.

Operates reliably at industrial temperature ranges ensuring long-term stability. Eases design integration with 14-pin SOIC surface mount package footprint.

The product is ideal for electronics manufacturing, embedded control systems, and semiconductor logic circuit designs. Find more semiconductor and inverter ICs in EnvMart’s comprehensive electronics category to suit your PCB design requirements.
