DiodesZetex Schmitt Trigger Input Hex Inverter 6 Elements 14-Pin SOIC 2V to 6V 74HC14S14-13

DiodesZetex 74HC14S14-13 is a high-speed Hex Inverter logic IC with Schmitt trigger inputs, housed in a 14-pin SOIC surface-mount package. It contains six inverter elements and operates at a supply voltage range of 2V to 6V, suitable for various electronic circuits requiring signal shaping and noise immunity.

The Schmitt trigger input design provides improved signal integrity by offering hysteresis for noisy or slowly changing input signals. This makes the IC ideal for applications involving waveform shaping, switching, and signal conditioning in industrial, laboratory, and electronic manufacturing environments.

With a maximum propagation delay of 190 nanoseconds at specified load capacitance, the 74HC14S14-13 enables efficient timing performance in digital logic circuits. The push-pull output type ensures robust signal drive capabilities with a maximum high-level output current of -4mA and low-level output current of 5.2mA.

This IC is rated to operate from -40°C to 125°C, ensuring reliability across extended temperature ranges required in diverse field conditions. The compact SOIC package type provides a minimum footprint for PCB designs, with detailed dimensions of length 8.74mm, width 3.99mm, and height 1.48mm.

The 74HC family series by DiodesZetex incorporates CMOS technology for low power consumption and meets international ESD standards including machine and human body model protections. This product is manufactured in China and is ideal for electronic component assemblers, OEMs, and end users looking for dependable high-speed logic ICs.

This hex inverter IC features Schmitt trigger inputs for noise immunity. Contains 6 inverter elements per chip designed to provide push-pull output. Operates within a supply voltage range of 2V to 6V. Maximum propagation delay time at load capacitance is 190 nanoseconds.

Supports both minimum and maximum operating temperatures from -40°C to 125°C. Compact SOIC surface mount package with 14 pins (pin count). Maximum high-level output current is -4mA and maximum low-level output current is 5.2mA.

Dimensions are 8.74mm length, 3.99mm width, and 1.48mm height. Designed with CMOS circuitry for low power consumption and stability. Exceeds ESD protection standards including 200V machine model and 2000V human body model.
