Texas Instruments Hex Inverter CMOS Logic IC 6 Elements 16-Pin PDIP CD4049UBE

Texas Instruments CD4049UBE is a Hex Inverter logic IC using CMOS technology, featuring 6 inverter elements in a 16-pin PDIP package. This device supports both DTL and TTL output types, making it versatile for various digital logic applications.

Designed for robust use, the CD4049UBE operates between supply voltages of 3 to 18 volts and functions reliably in a temperature range of -55°C to 125°C, suitable for industrial and laboratory environments. The IC offers a maximum propagation delay of 140 nanoseconds, enabling efficient signal processing.

The device provides a maximum low level output current of 26mA and a maximum high level output current of -0.48mA, which supports interface compatibility with several logic families. It does not implement Schmitt Trigger inputs, focusing on pure inverter functionality across 6 elements per chip.

Packaged in a 16-pin dual inline package (PDIP), the CD4049UBE is ideal for through-hole PCB mounting applications within electronics manufacturing and prototyping sectors.

This IC belongs to the CD4049UB series from Texas Instruments and does not have specific automotive standards certifications. It is widely used in electronic component assemblies, power and connectors, semiconductor logic circuits, and inverter IC designs.

This IC operates on CMOS technology with inverter logic function. It features 6 inverter elements per chip for multiple uses. The device supports input type CMOS and output types DTL and TTL. Maximum propagation delay time is 140 nanoseconds at CL.

Supply voltage ranges from 3V minimum up to 18V maximum. The IC operates across a wide temperature range from -55°C to 125°C for reliability. Pin count is 16 in PDIP package ensuring easy through-hole mounting. Output currents include maximum high level output at -0.48mA and maximum low level output at 26mA.

It is part of the CD4049UB series and does not support Schmitt Trigger inputs. The IC does not carry automotive certification standards.

This product is excellent for electronic manufacturing, laboratory instruments, semiconductor applications, and embedded system development. Explore the Electronics & Electricals category at EnvMart for more semiconductor components and inverter ICs from leading brands.

Explore more products in our Inverters ICs category.
