onsemi CMOS Inverter 2-Element TTL Input Open Drain 14-Pin SOIC MC74AC05DG

onsemi MC74AC05DG is a CMOS inverter providing 2 elements per chip with TTL compatible inputs and open drain outputs. This 14-pin SOIC packaged device operates from 2 volts minimum up to a maximum supply voltage of 6 volts, making it suitable for a variety of low voltage digital logic circuits.

The inverter features a maximum propagation delay time of 9 nanoseconds under specified load conditions, allowing for high-speed switching performance in industrial and commercial electronic devices.

Designed with surface mount technology, its compact dimensions of 8.75mm length, 4mm width, and 1.5mm height enable efficient PCB space utilization. The device functions reliably across a broad temperature range from -40°C to 85°C, suitable for industrial environments.

The maximum output current capabilities include -24mA for high level outputs and 24mA for low level outputs, ensuring adequate drive strength for downstream components. This inverter is part of the MC74AC05 series and provides TTL compatible inputs, enhancing its versatility in mixed logic designs. It does not include a Schmitt Trigger input.

The device is optimized for applications requiring fast, reliable switching and low power consumption. It is widely used in industrial automation, control systems, and embedded electronics requiring compact logic ICs. The open drain output type allows wired-AND logic configurations and simplifies level shifting.

Surface mount packaging supports modern manufacturing and assembly processes. Its robust construction and compliance with standard logic family inputs make it ideal for electronic circuitry needing dependable inverter functions.
