onsemi Schmitt Trigger Input Inverter 6 Elements, 14-Pin SOIC, 3 to 18V Supply MC14106BDR2G

onsemi MC14106BDR2G is a robust 6-element Schmitt Trigger Input Inverter designed with a 14-pin SOIC surface mount package, optimized for industrial, automotive, and electronic applications requiring reliable logic inversion and signal shaping.

Featuring a wide operating voltage range from 3 volts minimum to 18 volts maximum, the device ensures versatility across different power supply conditions common in automotive and industrial control systems. Its input includes Schmitt Trigger characteristics to improve noise immunity and signal integrity in demanding environments.

The inverter delivers single-ended output with maximum high level output current of -4.2mA and low level output current of 4.2mA, supporting efficient signal driving capabilities. Propagation delay time is tightly controlled at a maximum of 250 nanoseconds at the specified load capacitance, enabling high-speed switching requirements.

Dimensionally compact, the SOIC package measures 8.75mm in length, 4mm in width, and 1.5mm in height, facilitating PCB real estate savings. It is designed to operate reliably over a wide temperature range from -55°C to 125°C, making it suitable for harsh environmental conditions.

As part of the ON Semiconductor 4000 CMOS logic family and MC14106B series, this inverter complies with the automotive standard AEC-Q100, underscoring its quality and durability standards for automotive electronic components.

This inverter IC is commonly applied in automotive controls, industrial automation, signal conditioning circuits, and other electronics requiring dependable logic inversion with noise immunity.

Includes 6 inverter elements with Schmitt Trigger input for noise immunity. Operates over a wide voltage range of 3 to 18 volts. Maximum propagation delay time at CL is 250 nanoseconds. Maximum operating temperature ranges from -55°C to 125°C.

Configured in a 14-pin surface mount SOIC package measuring 8.75mm length, 4mm width, and 1.5mm height. Output type is single-ended with high and low level output currents of -4.2mA and 4.2mA respectively. Complies with automotive standard AEC-Q100 for enhanced reliability.

Belongs to the 4000 CMOS logic family series by onsemi. Explore the extensive catalog of semiconductors and inverters at EnvMart for industrial and commercial projects.
