Texas Instruments 8 Through Hole Binary Shift Register 14 Pin PDIP SN74HC164N
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 4.57mm |
| Length | 19.69mm |
| Model | SN74HC164N |
| Mount Type | Through Hole |
| Compatibility | Input CMOS, Output CMOS |
| Series | SN74HC164 |
| Maximum Operating Temperature | 85°C |
| Number Of Stages | 8 |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Operating Voltage | 2 to 6 V |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Number of Elements | 1 |
| Maximum Supply Voltage | 6V |
| Logic Family | HC |
| Logic Function | Shift Register |
| Minimum Supply Voltage | 2V |
| Direction Type | Uni-Directional |
| Reset Type | Asynchronous |
| Counter Type | Binary |
| Counter IC Clock Frequency | 21 MHz (4.5V), 4.2 MHz (2V), 25 MHz (6V) |
| Preset Type | Asynchronous |
Key Features
- This shift register belongs to the 74HC family using high-speed CMOS logic technology.
- The IC operates on a voltage range of 2 to 6 volts with low power consumption.
- It features asynchronous reset and preset types for flexible control.
- The device supports uni-directional binary counting with a clock frequency up to 25 MHz at 6V.
- The IC package dimensions are 19.69mm in length and 4.57mm in height.
- Typical applications include digital logic circuits and binary data handling in industrial and laboratory electronics.
- The component meets RoHS standards ensuring compliance with environmental directives.
Product Description
Texas Instruments SN74HC164N is an 8-stage binary shift register incorporated in a 14-pin PDIP package designed for through-hole mounting applications. It is part of the 74HC family which utilizes high-speed CMOS technology to deliver fast switching speeds while maintaining low power consumption, making it suitable for a variety of electronic circuit designs.
This IC functions as a unidirectional binary shift register featuring asynchronous reset and preset capabilities for convenient digital control. Its operating voltage ranges from 2V to 6V, with a maximum clock frequency of 25 MHz at 6V supply, enabling high-speed operations in timing and counting applications.
The device's physical dimensions, including a length of 19.69mm and height of 4.57mm, make it compatible with standard through-hole PCB designs. It has a pin count of 14, with widespread use in logic IC circuits requiring shift register functionality.
SN74HC164N meets RoHS environmental compliance standards, ensuring ecological safety for industrial and commercial usage. It is widely utilized in digital electronics, control systems, and electronic instrumentation suitable for industrial, laboratory, manufacturing, and educational environments.
This Shift Register IC operates on a voltage range of 2 to 6 volts. High-speed CMOS logic affords a clock frequency capability of up to 25 MHz. Asynchronous reset and preset features support robust circuit control. Through-hole mounting with a 14-pin PDIP package facilitates easy PCB integration.
Compliance with RoHS guarantees environmentally responsible manufacturing.
This product is ideal for applications requiring reliable binary data shifting in electronic and digital equipment. Browse further in the semiconductor and logic IC categories at EnvMart for compatible components and accessories.
