onsemi Surface Mount 1 Element Shift Register 4000 Series SOIC 16-Pin MC14094BDR2G

onsemi MC14094BDR2G is a surface mount shift register from the 4000 series logic family designed for reliable operation across a wide voltage and temperature range. Encapsulated in a 16-pin Small Outline Integrated Circuit (SOIC) package, it measures 10mm in length, 4mm in width, and 1.75mm in height. The shift register allows sequential data transfer and is equipped with a positive edge trigger for precise timing control.

This shift register operates effectively between 3V minimum and 18V maximum supply voltage, making it versatile for various low power and automotive electronic applications. It supports operation up to a maximum temperature of 125°C, meeting the rigor of automotive standards with AEC-Q100 certification.

Belonging to the renowned MC14094B series of CMOS logic ICs, the device exhibits low power consumption and high noise immunity, essential for demanding industrial environments.

Applications include industrial control systems, automotive electronics, and general-purpose shift register operations within embedded electronic designs. The compact SOIC package facilitates easy surface mounting on PCBs, supporting efficient manufacturing processes.

This shift register operates with a wide supply voltage range from 3V to 18V. Equipped with positive edge trigger for accurate data shifting. Maximum operating temperature withstand capacity of 125°C suitable for automotive use.

Compact 16-pin SOIC package dimensions of 10mm x 4mm x 1.75mm. Meets AEC-Q100 automotive standards for enhanced reliability. Part of the MC14094B CMOS logic family ensuring low power consumption. Used extensively in industrial, automotive, and embedded electronic applications.
