Molex Easy-On 1 mm Pitch 5 Way Right Angle Female FPC Connector, Solder Termination 52207-0560

Molex 52207-0560 Easy-On 1 mm Pitch 5 Way Right Angle Female FPC Connector is a surface mount connector designed to provide reliable interconnections in space-constrained electronic assemblies. Featuring a 1.00 mm pitch and 5 contacts, it supports current ratings up to 1 amp and voltage ratings up to 30 volts.

This connector incorporates a slide-type actuator that provides zero insertion force (ZIF) during FPC insertion, which minimizes wear during repeated mating cycles. The right angle orientation with top positioned contacts enables efficient PCB layouts where vertical height is limited.

The contacts are made from phosphor bronze and plated with gold over nickel to ensure excellent conductivity, corrosion resistance, and long-term reliability. The locking mechanism secures the Flexible Printed Circuit firmly without risk of accidental disconnection.

Constructed with a robust nylon housing, this connector offers mechanical protection and electrical insulation. It is suitable for operation in environments ranging from -30°C to 85°C, making it appropriate for automotive navigation, digital cameras, home security devices, tablet/notebook PCs, patient monitors, GPS units, smartphones, and other compact electronics.

Easy-On design offers repeatable cycling with minimum wear. Slide actuator allows easy insertion and secure connection. Right angle mount with solder termination provides secure PCB retention with strain relief. Gold plated phosphor bronze contacts ensure reliable electrical performance.

Durable nylon housing provides insulation and mechanical stability. Operates reliably in a broad temperature range from -30°C to +85°C. Rated for 30 V and 1 A current suitable for low power applications. Applications include automotive, consumer, medical, datacom, and mobile phone industries.

Molex 52207-0560 connectors belong to the 52207 series of ZIF SMT mount FPC connectors, known for their quality and space-saving design. Their slide actuator and locking mechanism assure both ease of use and robust connectivity in a variety of industrial and consumer electronic products.
