Molex 16-Way IDC Connector Male for Through Hole, 1 Row, 1.2A Current, 1.27mm Pitch, 250V AC, Unshrouded, Tin 90325-0016
Specifications
| Country of Origin | Ireland |
|---|---|
| Voltage | 250V ac |
| Brand | Molex |
| Orientation | Straight |
| Current | 1.2A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | Picoflex |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| 90814-00xx | SMT, Tin, with PCB pegs |
| 90814-06xx | SMT, Tin, no PCB pegs |
| 90814-07xx | SMT, Tin, no PCB pegs |
| 90814-08xx | SMT, Tin, with PCB pegs |
| 90814-09xx | SMT, Tin, with PCB pegs |
| 90814-38xx | SMT, Gold flash, with PCB pegs |
| 90814-39xx | SMT, Gold flash, with PCB pegs |
| 90325-00xx | Through hole, Tin, with PCB pegs |
| 90325-90xx | Through hole, Tin, with PCB pegs |
| 93405-05xx | Reverse footprint, SMT, Tin, no PCB pegs |
Key Features
- Supports 16 contacts arranged in a single row for compact interfacing.
- Rated at 1.2A current capacity with 250V AC voltage tolerance.
- Features 1.27mm pitch providing 50% space saving compared to traditional pitch connectors.
- Constructed with brass contacts, tin over nickel plating and polybutylene terephthalate housing.
- Unshrouded male connector with straight orientation ensuring easy board connection.
- Suitable for automotive and consumer electronics industries requiring robust vibration resistance.
- Operating temperature range from -40°C to 105°C for versatile application environments.
- Mating height low profile of 6.4mm reduces space usage on PCB assemblies.
Product Description
Molex 90325-0016 is a 16-Way IDC Connector Male designed for through-hole mounting, suitable for high-density PCB assemblies requiring compact and reliable connections.
This unshrouded connector features a single row of 16 contacts with 1.27mm pitch, significantly reducing space compared to traditional connectors. It supports a current of 1.2A and voltage up to 250V AC, making it appropriate for demanding electronic applications.
The contacts are made of brass with tin over nickel plating to ensure excellent conductivity and corrosion resistance. Housing is crafted from durable polybutylene terephthalate, providing mechanical strength and temperature resilience from -40°C to 105°C.
Its straight orientation and through-hole mount type offer ease of PCB assembly and robustness. The connector includes friction lock and integral strain relief to resist vibration and shock, suitable for automotive and consumer electronics.
The connector series Picoflex offers 50% space saving, lower profile mating height of only 6.4mm, and options with polarization features to ensure proper mating. This makes it ideal for applications requiring miniaturized and secure wire-to-board connections.
Supports 16 contacts in a compact 1-row layout. Rated for 1.2A current and 250V AC voltage. 1.27mm pitch provides space efficient connection. Brass contacts with tin over nickel plating. Polybutylene terephthalate housing for durability.
Through hole mount with straight male contacts. Operating temperature range -40°C to 105°C. Friction lock and polarization for secure mating. High resistance to vibration and shock for automotive use. Manufactured in Ireland adhering to quality standards.
This IDC Connector is suitable for industrial, automotive, consumer electronics, and manufacturing environments requiring reliable and space-efficient wire-to-board connectivity solutions. Browse Molex products at EnvMart for trusted quality connectors and related components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector is rated for a current of 1.2A and a voltage of 250V AC.
The contacts in this IDC connector have a pitch of 1.27mm, providing a space-efficient design.
The contacts are made of brass with tin over nickel plating, and the housing is constructed from polybutylene terephthalate.
This model operates within a temperature range of -40°C to 105°C, making it suitable for various environments.
This connector is designed for through-hole mounting, allowing for easy PCB assembly.
It supports a total of 16 contacts arranged in a single row.
This model features a straight orientation, facilitating straightforward board connections.
Yes, it is suitable for automotive applications due to its high resistance to vibration and shock.
This connector belongs to the Picoflex series, which offers space-saving designs.
Yes, it includes a friction lock and integral strain relief to ensure secure mating.
This connector is manufactured in Ireland, adhering to quality standards.
It is suitable for industrial, automotive, consumer electronics, and manufacturing environments requiring reliable wire-to-board connectivity.
