Molex 26-Way IDC Connector Male for Through Hole, 1 Row 90325-0026
Specifications
| Country of Origin | Ireland |
|---|---|
| Voltage | 250V ac |
| Brand | Molex |
| Orientation | Straight |
| Current | 1.2A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | Picoflex |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 26 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| 90814-00xx | SMT, Tin, with PCB pegs |
| 90814-06xx | SMT, Tin, no PCB pegs |
| 90814-07xx | SMT, Tin, no PCB pegs |
| 90814-08xx | SMT, Tin, with PCB pegs |
| 90814-09xx | SMT, Tin, with PCB pegs |
| 90814-38xx | SMT, Gold flash, with PCB pegs |
| 90814-39xx | SMT, Gold flash, with PCB pegs |
| 90325-00xx | Through hole, Tin, with PCB pegs |
| 90325-90xx | Through hole, Tin, with PCB pegs |
| 93405-05xx | Reverse footprint, SMT, Tin, no PCB pegs |
Key Features
- Supports up to 26 contacts with a 1.27mm pitch for compact design.
- Rated for 250V AC voltage and current of 1.2A ensuring stable performance.
- Features a robust through-hole mount with a straight orientation for PCB housing.
- Contact plating is tin over nickel on brass material for corrosion resistance.
- Operating temperature range from -40°C to 105°C suitable for harsh conditions.
- Housing made from durable polybutylene terephthalate for mechanical strength.
- Unshrouded male connector ideal for friction lock and polarization.
- Complies with Picoflex series specifications for automotive and consumer electronics.
Product Description
Molex 90325-0026 IDC Connector is a 26-way male connector designed for through hole PCB mounting with a single row configuration and 1.27 mm pitch spacing. This connector is part of the Picoflex series, specializing in low profile and high-density wire-to-board connections suitable for demanding industrial and automotive environments.
The connector supports a maximum current of 1.2A and voltage rating of 250V AC, providing reliable electrical performance. The contact material is brass with tin over nickel plating, ensuring resistance to corrosion and maintaining good conductivity. The housing is constructed from polybutylene terephthalate, offering mechanical durability and stability under temperature ranges from -40°C to 105°C.
It features a through-hole mount type and a straight orientation, simplifying PCB integration with a secure fit enhanced by friction lock and polarisation mechanisms.
This unshrouded male connector is well-suited for automotive and consumer electronics applications that require low-profile and high-density connections, providing 50% space saving compared to traditional pitch connectors. The Picoflex IDT series ensures excellent vibration and shock resistance for robust operation.
26 contacts with 1.27 mm pitch for compact wiring. Through hole mount allows secure PCB integration. Brass contacts plated with tin over nickel for durability. Housing of polybutylene terephthalate for mechanical strength.
Operating temperature from -40°C to 105°C supports harsh environments. Part of the Picoflex series optimised for space saving and reliability. Unshrouded male connector with friction lock and polarisation. Suitable for automotive, industrial, and consumer electronic wiring.
Choose Molex IDC Connectors for dependable wire-to-board electrical connections optimized for high-density and low profile industrial and automotive applications. Explore more connectors and electronic components at EnvMart for your specialized requirements.
