Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header 2 Contact 4.2 mm Pitch 2 Row Shrouded 39-29-4029

Molex 39-29-4029 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a high-quality shrouded PCB connector designed for wire-to-board power applications. With 2 contacts arranged in 2 rows and a 4.2 mm pitch, it supports up to 9 amperes current per circuit, making it suitable for demanding electrical and electronic industrial use cases.

The connector housing is made of durable nylon material and designed as scoop-proof to protect against arcing and terminal damage during mating. Fully isolated brass contacts are gold plated to ensure excellent conductivity and corrosion resistance.

Its right angle orientation and through hole mount type allow easy and secure integration onto printed circuit boards (PCBs). The connector system features polarization and keying to ensure proper alignment and prevent mismating with the receptacle.

Additional feature includes a positive locking mechanism that provides a secure fit with an audible click confirming full mating. These connectors can withstand operating temperatures ranging from -40°C up to 105°C, with a voltage rating of 600 volts, accommodating a wide range of industrial and commercial applications.

Mini-Fit Jr series connectors are ideal for use in consumer white goods, office and industrial automation equipment, rack-mount servers, routers, switches, and other applications requiring reliable power interconnection in compact spaces.

Handles up to 9A current per circuit for reliable power delivery. Features fully isolated brass contacts with gold plating for long-term durability. Nylon scoop-proof housings protect against terminal damage during mating.

Right angle orientation suitable for PCB through hole mounting applications. Polarization and keying features prevent connector mismating and misalignment. Positive locking mechanism with audible click ensures secure connections.

Operational temperature range: -40°C to 105°C, suitable for varied environments. Voltage rating up to 600V for versatile industrial use. Versions available with PCB retention pegs and mounting flanges for secure PCB placement.

Explore the range of Molex PCB Headers and connectors on EnvMart for industrial, manufacturing, electronics assembly, and automation needs. Reliable power connectors simplify your design and improve system longevity.
