Molex C-Grid III Series Right Angle Through Hole PCB Header 6 Contacts 2.54mm Pitch Single Row Shrouded 90136-2206
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Features a right angle orientation for space-efficient PCB mounting.
- Utilizes brass contacts plated with gold for corrosion resistance.
- Designed for a 3A current rating and 350V voltage withstand.
- Constructed with durable polyester housing to ensure long service life.
- Operates reliably from -55°C to 125°C temperature range.
- Includes a tail pin length of 2.9 mm and mating pin length of 6.75 mm for secure solder connections.
- Shrouded connector design improves safety and prevents misalignment.
- Compatible with Molex C-Grid III series locking housings for enhanced mechanical retention.
Product Description
Molex 90136-2206 C-Grid III Series right angle through hole PCB header provides a reliable wire-to-board connection with a shrouded single row of six male contacts. It features a 2.54 mm pitch and is designed for a current rating of 3 Amperes and voltage rating of 350 Volts, ensuring safe operation in electronic assemblies.
The connector utilizes brass contacts with gold plating for enhanced corrosion resistance and electrical performance. Its polyester housing offers mechanical durability and thermal stability across a wide operating temperature range from -55°C up to 125°C.
The right angle orientation and through hole mounting type allow efficient PCB space utilization and robust mechanical attachment. The connector's shrouded design improves user safety and prevents incorrect mating.
The product includes tail pin lengths of 2.9 mm and mating pin lengths of 6.75 mm, enabling secure solder joint formation and reliable electrical contact. This PCB header is compatible with Molex's C-Grid III locking housings, providing mechanical retention to avoid accidental disengagement.
This PCB header is widely used in electronic components, power and connectors applications, suitable for industrial, manufacturing, and commercial electronics assembly requiring dependable wire-to-board connections.
Right angle orientation enables compact PCB layout. Gold-plated brass contacts ensure conductivity and durability. Polyester housing withstands high temperatures and conditions. 3A current rating supports moderate power applications.
350V voltage rating ensures safety in typical circuitry. Industry standard 2.54 mm pitch facilitates compatibility. Shrouded design prevents connector damage and misalignment. Through hole mounting offers secure PCB fixation.
Suited for electronics manufacturing and industrial use. Explore more Molex connectors and PCB header solutions in the electronics category at EnvMart.
Explore more products in our PCB Headers category.
