Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header 8 Contact 3 mm Pitch 1 Row Shrouded 43650-0800

The Molex 43650-0800 Micro-Fit 3.0 Series Right Angle Through Hole PCB Header is a high-performance, compact, wire-to-board connector solution designed for reliable power and signal distribution on printed circuit boards. With 8 contacts arranged in a single row and a precise 3 mm pitch, this PCB header supports currents up to 5 amperes and voltages up to 250 volts, making it suitable for varied industrial, consumer, and telecommunications applications.

Constructed with a shrouded housing made from high-temperature resistant liquid crystal polymer (UL 94V-0), the connector can withstand soldering processes up to 265°C, ensuring durability during manufacturing and in operation. The right-angle orientation of the header facilitates efficient PCB layout and connector alignment, particularly in tight spaces.

Positive latching features, including locking ramps on the housing, provide secure mating and prevent accidental disconnection. Snap-in plastic peg locks enable solid through-hole mounting, while the connector remains SMT compatible for streamlined assembly. Contacts are crafted from brass with tin plating to offer reliable electrical conductivity and solderability.

This Micro-Fit 3.0 header excels in applications requiring compact yet robust power connectors, including military COTS devices, solar power systems, consumer appliances such as dryers and refrigerators, data communications equipment like routers and servers, medical devices, telecommunications infrastructure, and gaming terminals.

Key product features include high current capacity in a small footprint, robust mechanical and electrical reliability due to fully isolated dual beam terminals, and compliance with glow wire safety standards. The connector housing material and design promote safe operation in challenging thermal environments. This product ensures efficient, stable power and signal connections in demanding electronics environments.

Designed with a 3 mm pitch and a single row layout for compact PCB integration. The shrouded housing made of liquid crystal polymer ensures durability and high temperature resistance. Features positive latching and snap-in plastic peg locks for stable and secure PCB mounting.

Capable of carrying currents up to 5A at 250V for reliable power distribution. Contacts are brass plated with tin for effective soldering and conductivity. Operates reliably within a wide temperature range from -40°C to 105°C.

Right angle orientation is optimal for PCB space management and connector alignment. Through-hole mounting design is SMT compatible for cost-effective assembly. Explore more Micro-Fit connectors and related PCB header solutions to find the ideal fit for your electronic design and assembly needs at EnvMart.
