Molex C-Grid III Series Straight Through Hole PCB Header, 34 Contacts, 2.54 mm Pitch, 2 Row, Shrouded 90130-1234
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 34 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Supports a current rating of 3A for demanding electronic applications.
- Features a polyester housing material ensuring durability and heat resistance.
- Designed with 2 rows of straight, male, shrouded contacts for secure mating.
- Gold-plated brass contacts offer excellent conductivity and corrosion resistance.
- Suitable for through hole mounting with solder termination.
- Operating temperature range from -55°C to 125°C for harsh environments.
- Mating pin length of 6.75 mm and tail pin length of 2.9 mm for secure connections.
- High voltage rating of 350V for industrial and commercial electronics.
Product Description
Molex 90130-1234 C-Grid III Series Straight Through Hole PCB Header is engineered for high-performance wire-to-board connections in industrial and electronic applications. This header features 34 gold-plated brass contacts arranged in two rows with a 2.54 mm pitch, providing robust electrical performance. The polyester housing is shrouded, protecting contacts and ensuring reliable mating with locking housings.
With a current rating of 3 amperes and a voltage rating up to 350 volts, this PCB header is suitable for various electronics, including embedded systems, industrial control units, and communication devices. Its through-hole mount and solder termination ensure solid mechanical and electrical bonds with printed circuit boards.
The connector operates reliably across a wide temperature range from -55°C to 125°C, making it versatile for use in demanding environments like manufacturing equipment and instrumentation. The male contact gender with 6.75 mm mating pin length and 2.9 mm tail pin length supports secure and stable wire-to-board interfacing.
This Molex header is part of the C-Grid III series, known for consistent performance and ease of integration into automated PCB assembly processes. The shrouded design adds extra protection by preventing misalignment and contact damage during insertion.
Supports 34 contacts in two rows at 2.54 mm pitch. Polyester shrouded housing for durability and protection. Solder termination and through-hole mounting for secure PCB attachment. Gold-plated brass contacts offer reliable conductivity and corrosion resistance.
Operates between -55°C and 125°C for wide industrial applicability. Rated for 3A current and 350V voltage for demanding applications. Ideal for industrial manufacturing, electronic assembly, and communication devices. Explore more PCB connectors and headers from trusted brands like Molex on EnvMart for all your electronic component needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 3A, making it suitable for demanding electronic applications.
It has a voltage rating of 350V, which is appropriate for industrial and commercial electronics.
This model features a pitch of 2.54 mm and includes 34 contacts arranged in two rows.
The operating temperature range for this header is from -55°C to 125°C, allowing it to function in harsh environments.
The housing is made from polyester, while the contacts are gold-plated brass, ensuring good conductivity and corrosion resistance.
It is designed for through-hole mounting with solder termination, ensuring secure attachment to printed circuit boards.
The mating pin length is 6.75 mm and the tail pin length is 2.9 mm, providing stable connections.
This model uses a wire-to-board connector system, suitable for various electronic applications.
Yes, this header is part of the C-Grid III series, known for its ease of integration into automated PCB assembly processes.
The contacts are arranged in a straight orientation, facilitating easy mating with compatible connectors.
The country of origin for this PCB header is India.
The contacts in this connector are male, designed for secure mating with female connectors.
