Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header 8 Contact 3 mm Pitch 1 Row Shrouded 43650-0812

Molex 43650-0812 Micro-Fit 3.0 Series right angle surface mount PCB header is a compact wire-to-board connector designed for reliable, high-current power distribution in electronics. This header features 8 contacts arranged in a single row with 3 mm pitch and a shrouded housing to ensure secure connections.

The housing is constructed from high temperature thermoplastic material compliant with UL 94V-0, capable of withstanding temperatures up to 265°C during IR reflow soldering. Its positive latching design with a locking ramp provides secure mating to prevent accidental disconnections, essential for industrial and commercial electronic assemblies.

The brass contacts plated with tin are fully isolated inside the housing to minimize arcing and improve reliability. The solder tabs incorporated into the design enhance mechanical stability when surface mounted on PCBs. Operating voltage rating is 250V with a maximum current capacity of 5A, making it suitable for low to mid power electronic and electrical applications.

This header operates reliably within a temperature range from -40°C to 125°C, supporting demanding environments including telecommunications, consumer appliances, medical devices, and industrial controls. The right angle orientation facilitates efficient wire routing on PCB assemblies.

Compact Micro-Fit 3.0 connector system ideal for low to mid power applications. Supports up to 5A current carrying capacity in a small footprint. High-temperature UL 94V-0 thermoplastic housing suitable for IR reflow soldering.

Positive latching design for secure connector mating. Brass contacts with tin plating for reliable electrical performance. Solder tabs for robust surface mount PCB attachment. Wide operating temperature range from -40°C to 125°C.

Right angle orientation for wire-to-board connection efficiency.

Applications include military COTS equipment, solar power systems, consumer products such as dryers and refrigerators, telecommunications equipment, automotive electronics, gaming terminals, and medical devices. This connector is manufactured in Mexico with high quality standards ensuring dependable performance.
