Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header, 18 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1807

Free Delivery in India | Lowest Global Shipping Charges

Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header, 18 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1807

Name: Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header, 18 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1807
Brand: Molex
SKU: 206472
Price: 8.6 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Right Angle
Current	5A
Mount Type	Surface
Housing Material	Thermoplastic
Contact Material	Brass
Series	Micro-Fit 3.0
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	3mm
Contact Plating	Gold
Number of Contacts	18
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Mating Pin Length	3mm

Key Features

High current capacity of 5A suitable for low to mid power applications.
Housing made of thermoplastic with high temperature tolerance for IR reflow soldering.
Right angle orientation with surface mount type for PCB integration.
Gold plated brass contacts ensure reliable electrical performance and corrosion resistance.
Dual beam terminals fully isolated to reduce arcing and improve contact reliability.
Incorporates positive latching with locking ramp to prevent accidental disconnections.
Metal press-fit retention clips secure the header firmly to the PCB.
Operating temperature range from -40°C to 125°C.

Product Description

Molex 43045-1807 Micro-Fit 3.0 Series right angle surface PCB header is a premium wire-to-board connector ideal for compact power distribution solutions in electronic components, power & connectors sectors. It features 18 gold-plated brass contacts arranged in 2 rows with a 3 mm pitch and a shrouded housing ensuring secure and reliable mating.

The thermoplastic housing withstands high temperatures up to 265°C during IR reflow soldering, making it suitable for demanding manufacturing processes. The connector incorporates positive latching and metal press-fit retention clips that secure the header firmly to the PCB, eliminating accidental disconnections and enhancing mechanical stability.

This Micro-Fit 3.0 header supports up to 5A of current, making it capable of handling low to mid-level power requirements effectively. The fully isolated dual beam terminals reduce arcing risks and ensure consistent electrical performance over the product's lifespan. Operating temperature ranges from -40°C to 125°C enable usage in a wide variety of environments.

The connector is suitable for diverse industrial applications including military Commercial Off The Shelf (COTS) equipment, solar power systems, consumer products such as dryers and refrigerators, data communications including routers and servers, medical devices, telecommunications infrastructure, and gaming terminals.

High current rating with small footprint. Thermoplastic housings compliant with IR reflow soldering. Positive latching for secure mating. Gold-plated brass contacts for corrosion resistance. Press-fit retention for PCB stability.

Wide temperature operation range. Fully isolated terminals for reliable performance. SMT compatible through hole design reduces manufacturing costs. Glow Wire Compliant for safety assurance.
