Molex KK 254 Series Right Angle Through Hole Pin Header 3 Contact, 2.54 mm Pitch, 1 Row, Unshrouded 22-12-4032

Free Delivery in India | Lowest Global Shipping Charges

Molex KK 254 Series Right Angle Through Hole Pin Header 3 Contact, 2.54 mm Pitch, 1 Row, Unshrouded 22-12-4032

Name: Molex KK 254 Series Right Angle Through Hole Pin Header 3 Contact, 2.54 mm Pitch, 1 Row, Unshrouded 22-12-4032
Brand: Molex
SKU: 206359
Price: 1.25 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Right Angle
Current	4A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	KK 254
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	3.8mm
Mating Pin Length	2.54mm

Key Features

The header features a right angle orientation for versatile PCB mounting.
Contact pins are gold plated brass for optimal conductivity and corrosion resistance.
Constructed with a high-quality Nylon 6/6 UL 94V-0 housing material.
It supports currents up to 4A and a voltage rating of 250V.
Designed as an unshrouded male pin header with a single row of contacts.
Suitable for through-hole solder mounting ensuring secure and stable connections.
Operates reliably in temperatures ranging from -40°C to 105°C.
Tail pin length of 3.8 mm allows effective PCB penetration and solder joint formation.

Product Description

Molex 22-12-4032 KK 254 Series Right Angle Through Hole Pin Header is a precision electronic component designed for robust PCB interfacing in industrial and commercial electronics applications. Featuring 3 male contacts arranged in a single row with a 2.54 mm pitch, this header allows secure wire-to-board connections without shrouding.

The housing material is a high-grade Nylon 6/6 rated UL 94V-0, ensuring flame retardance and mechanical durability. Gold plating on brass contact pins guarantees excellent conductivity and corrosion protection, critical for sensitive electronic circuits. The header supports a maximum current of 4 A and sustained operation up to 250 V, suitable for demanding signal or power interfaces.

Its right-angle orientation facilitates versatile PCB mounting configurations, often used in compact electronics assemblies. The through-hole solder mounting ensures robust mechanical fixing and electrical reliability for long-term industrial use.

Operating temperature range from -40°C to +105°C makes this pin header suitable for a wide variety of environmental conditions including automotive, industrial control, and instrumentation systems.

The tail pin length of 3.8 mm and mating pin length of 2.54 mm allow compatibility with mate-lock housings such as the Molex 2695 Series with Lock, enabling secure cable connections. The unshrouded design permits easy access for soldering, inspection, and modifications.

The header’s Nylon wafer with end-to-end stacking capability enhances modular PCB design flexibility. Gold plating of contact area and tin plating of solder area optimize the pin header for reliable signal integrity and manufacturability.

This component has no specific certifications but meets industrial standards for connector safety and performance. Common use cases include industrial automation control panels, laboratory equipment, electronic prototyping, and general-purpose PCB interconnect applications.

Explore more Molex KK 254 Series PCB Headers at EnvMart for reliable electronic component solutions.
