Molex KK 254 Series Right Angle Through Hole Pin Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded, Nylon 22-12-4032

Molex 22-12-4032 KK 254 Series Right Angle Through Hole Pin Header provides precise and reliable wire-to-board connection in electronic applications. The header features 3 male brass contacts plated in gold, housed in a Nylon 6/6 UL 94V-0 natural body to ensure flame retardancy and mechanical durability.

Designed for through hole mounting in a single row with 2.54 mm pitch spacing, this right angle pin header facilitates space-saving PCB layouts while maintaining robust electrical contact rated at 250 V and 4 A. The unshrouded design allows for easy insertion and removal of mating connectors.

The tail pins extend 3.8 mm for solder termination, while the mating pins are 2.54 mm long for secure engagement. It supports a wide operating temperature range from -40°C minimum to 105°C maximum, suitable for industrial, electronic, and manufacturing equipment applications.

This header series is compatible with Molex 2695 Series housings featuring a friction lock mechanism that ensures a secure connection even in environments with vibrations. The Nylon housing allows end-to-end stacking to increase connector densities as needed.

The housing is constructed from Nylon 6/6 UL 94V-0 natural material providing flame retardant properties. Brass contacts with gold plating ensure superior conductivity and corrosion resistance. Right angle orientation with through hole mount type enables efficient PCB assembly.

The connector system is wire-to-board with unshrouded, male contacts. Voltage rating is 250 V with current carrying capacity up to 4 A. Operating temperature range from -40°C to 105°C allows versatility in various environments.

The mating pin length is 2.54 mm, and the tail pin length is 3.8 mm. No compliance standards are specified for this model.

This product is ideal for use in electronic component manufacturing, PCB assembly, industrial automation systems, and other electronics requiring reliable signal or power connections.
