Molex Milli-Grid Series Straight Surface PCB Header, 12 Contact(s), 2 mm Pitch, 2 Row, Shrouded 87832-1220

Molex 87832-1220 Milli-Grid Series Straight Surface PCB Header is a high-density, 12-contact wire-to-board connector with a 2 mm pitch arranged in 2 rows. It features a shrouded, straight orientation designed for surface mount technology (SMT) applications, providing reliable mechanical and electrical connections on printed circuit boards.

Constructed with a durable nylon housing and phosphor bronze contacts plated with 0.38 μm gold, this header ensures excellent conductivity and corrosion resistance. Its solder termination type enables secure and stable attachment to PCBs.

Operating within a temperature range of -55°C to 105°C and rated for a current of 2 amperes and 125 volts, the connector is suited for various electronics applications requiring compact and reliable interconnections.

The 87832-1220 header mates with Molex 51110 series receptacles, facilitating easy integration into existing Milli-Grid interconnection systems built on a 2 x 2 mm grid pattern. The shrouded design enhances protection and prevents incorrect mating, aiding in maintaining circuit integrity.

The connector features a 2 mm pitch and 2 rows for high-density PCB mounting. It is constructed with a nylon housing and phosphor bronze contacts plated with gold for reliable conductivity. The header is designed as straight orientation with surface mount technology (SMT) termination.

Operating temperature ranges from -55°C to 105°C ensuring dependable performance in varied environments. It is rated for 2 A current and 125 V operating voltage, suitable for moderate electrical applications. The device has a mating pin length of 2 mm and uses solder termination for secure connections.

The connector system is wire-to-board with shrouded design to prevent misalignment and protect contacts.

This PCB header is widely used in industrial, electronics manufacturing, telecommunications, and other electronic assembly environments where secure and compact PCB connections are critical. It enhances production efficiency by providing ready-to-insert connectivity with consistent quality.
