DiodesZetex NPN Transistor 6 A, 60 V, 4-Pin SOT-223 ZXTN2010GTA

DiodesZetex ZXTN2010GTA is a high-performance bipolar NPN transistor designed for efficient switching and amplification tasks in electronic circuits. This transistor supports a maximum DC collector current of 6 amperes and a maximum collector-emitter voltage of 60 volts, making it suitable for power and control applications within automotive and industrial environments.

Its 4-pin SOT-223 surface mount package ensures compactness and easy integration onto PCBs, supporting automated manufacturing processes. The device is configured as a single transistor with a minimum DC current gain (hFE) of 20 and can operate reliably in temperature ranges from -55°C up to 150°C.

With a maximum power dissipation of 3 watts and a transition frequency of 130 MHz, it balances power handling and speed for diverse uses in switching circuits and amplification stages. The ZXTN2010GTA complies with the stringent automotive standard AEC-Q101, confirming its robust quality for demanding automotive electronics applications.

Key features include its compact physical dimensions measuring 6.55 mm in length, 7.1 mm in width, and 1.65 mm in height, optimized for space-constrained designs. The transistor delivers up to 6 A collector current for power applications.

Rated for 60 V maximum collector-emitter voltage. Compact 4-pin SOT-223 package form. Low power dissipation of 3 W for efficient thermal management. Minimum DC current gain of 20 for reliable amplification. Wide operating temperature range from -55°C to 150°C.

High transition frequency of 130 MHz suitable for fast switching. Automotive-grade certification with AEC-Q101 standard. Physical dimensions support surface mount PCB assembly.

This transistor is extensively used in automotive electronics, industrial power control modules, and other semiconductor applications requiring reliable NPN switching components. It supports enhanced production efficiency through its surface mount design, meeting modern electronics manufacturing standards.
