Molex Slim-Grid Series Straight Surface PCB Socket 12-Contact 2 Row 1.27 mm Pitch Solder 78120-1207

Molex 78120-1207 Slim-Grid Series Straight Surface PCB Socket is a 12-contact, 2-row, 1.27 mm pitch solder type connector designed for secure board-to-board interfacing in high density electronic applications. Operating at 125 V and 1.4 A, this PCB socket features a liquid crystal polymer housing that withstands a wide temperature range from -55°C to 105°C, ensuring performance reliability under diverse environmental conditions.

The socket employs a straight orientation with polarization slots and tabs to prevent mismating, while locking windows and ramps provide a robust and secure mechanical connection. The gold-plated copper contacts enhance conductivity and resist corrosion, making this connector suitable for demanding electrical applications.

This Slim-Grid connector series is ideal for use in automotive electronics, industrial controls, consumer devices, lighting luminaries, and communication equipment such as hubs, routers, and switches. It supports compact designs with its 1.27 x 1.27 mm grid pitch, enabling flexible layout options in high density PCB assemblies.

Manufactured with precision, the product ensures accurate placement on PCB boards due to its surface mount type and reliable contact mechanism. The high-quality materials and design contribute to long-term durability and stable electrical connections in various industrial and commercial environments.

Users benefit from the connector’s compatibility with high-volume manufacturing processes and suitability for energy-efficient systems, white goods, and portable electronics. The Molex Slim-Grid Series represents an industry-standard solution for board-to-board connectivity offering performance, reliability, and ease of integration.

Features a high density 1.27 x 1.27 mm grid pattern for flexible design in compact spaces. Includes polarization slots and tabs that prevent incorrect orientation and mismating. Incorporates locking windows and ramps ensuring a secure and robust connection when mated.

Surface mount housing made of liquid crystal polymer for durability and thermal stability. Rated for 1.4 A current and 125 V voltage with gold-plated copper contacts for reliable electrical performance. Operates efficiently in temperatures ranging from -55°C to 105°C.

Ideal for automotive, industrial, and consumer electronics including routers, switches, and portable devices. Explore other PCB Sockets and connectors in the Electronics Components category on EnvMart for a comprehensive selection of industrial-grade electronic solutions.
