Nexperia 33 V 300 mW 5% Surface Mount Zener Diode 2-Pin UMD BZX384-C33,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 33 V 300 mW 5% Surface Mount Zener Diode 2-Pin UMD BZX384-C33,115

Name: Nexperia 33 V 300 mW 5% Surface Mount Zener Diode 2-Pin UMD BZX384-C33,115
Brand: Nexperia
SKU: 164464
Price: 0.05 USD
Availability: InStock



Category Zener Diode Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	2.7mm
Model	BZX384-C33,115
Mount Type	Surface
Series	BZX384
Maximum Operating Temperature	150°C
Package Type	UMD
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	300mW
Diode Configuration	Single
Test Current It	2mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	33V
Zener Type	Voltage Regulator
Maximum Zener Impedance	80Ω
Typical Voltage Temperature Coefficient	29.7mV/°C
Surface Mount case	SOD-323 (SC-76)
Diodes Inc, 24V Zener Diode 2.5% 500 mW SMT 2-Pin SOD-323FBrand	DiodesZetex

Key Features

The diode features a nominal Zener voltage of 33 V with ±5% tolerance.
It has a maximum power dissipation of 300 mW for reliable voltage regulation.
The device uses a surface mount 2-pin UMD (SOD-323) package.
Operates over a temperature range from -65°C to 150°C.
Maximum reverse leakage current is a low 50 nA ensuring high efficiency.
Typical voltage temperature coefficient is 29.7 mV/°C for stable performance.
The product meets automotive standard AEC-Q101 ensuring quality and durability.
Compact dimensions are 2.7 mm length and 1.1 mm height.

Product Description

Nexperia BZX384-C33,115 is a high-quality Zener diode designed for voltage regulation in electronic circuits requiring a stable 33 V reference and up to 300 mW power dissipation. It comes in a compact surface mount 2-pin UMD (SOD-323) package, suitable for modern electronics assembly and automated soldering processes.

This diode provides precise voltage regulation with a tolerance of ±5%, making it ideal for protecting circuits from voltage spikes or for use in voltage reference designs. The nominal Zener voltage is 33 V, and the device can safely dissipate up to 300 mW.

The component's operating temperature range of -65°C to +150°C supports automotive and industrial environments. A very low maximum reverse leakage current of 50 nA ensures minimal leakage losses, contributing to overall circuit efficiency. The typical voltage temperature coefficient of 29.7 mV/°C reflects its stable performance over varying thermal conditions.

The diode is qualified to meet the automotive AEC-Q101 standard, which attests to its robustness and reliability for automotive and industrial applications. Its small form factor with a length of 2.7 mm and height of 1.1 mm allows space-saving PCB design.

The diode configuration is single element for focused voltage regulation. Maximum Zener impedance is 80 Ω at the test current of 2 mA. Surface mount installation facilitates automated production and compact assembly. This component finds applications in power supplies, voltage regulators, and protective circuit designs in automotive, industrial, and consumer electronics sectors.

Choose Nexperia BZX384-C33,115 for dependable and precise voltage regulation in demanding environments. Explore the complete range of Zener Diodes and semiconductor components on EnvMart.
