Samtec ESQ Series Vertical Through Hole PCB Socket 4-Contact 2 Row 2.54 mm Pitch 5.7A 515V ESQ-102-12-G-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec ESQ Series Vertical Through Hole PCB Socket 4-Contact 2 Row 2.54 mm Pitch 5.7A 515V ESQ-102-12-G-D

Name: Samtec ESQ Series Vertical Through Hole PCB Socket 4-Contact 2 Row 2.54 mm Pitch 5.7A 515V ESQ-102-12-G-D
Brand: Samtec
SKU: 105009
Price: 2.07 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	515V
Brand	Samtec
Orientation	Vertical
Current	5.7A
Model	ESQ-102-12-G-D
Mount Type	Through Hole
Housing Material	Black Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	ESQ
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Max Cycles	100 with 10μ" (0.25μm) Au
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	4
Connector System	Board-to-Board

Key Features

Constructed from black glass filled polyester housing for durability.
Phosphor bronze contacts plated with gold ensure reliable conductivity.
Designed for board-to-board connection with solder termination.
Supports voltage up to 515V and operating temperature range from -55°C to 125°C.
Vertical orientation with 0.635 mm square tails suitable for PC/104 applications.
Normal insertion force of 125 grams ensures easy assembly and secure contact.
Maximum 100 mating cycles with 10μ" (0.25 μm) gold plating.
Ideal for industrial and electronic component assembly applications.

Product Description

Samtec ESQ-102-12-G-D is a versatile ESQ series vertical through hole PCB socket designed for robust electronic and industrial connections. It features 4 contacts arranged in 2 rows with a pitch of 2.54 mm, suitable for precise board-to-board interconnects in demanding environments.

The housing is made of black glass filled polyester, which provides excellent mechanical strength and thermal stability. Contacts are crafted from phosphor bronze and plated with gold to ensure long-term reliable conductivity and corrosion resistance.

This PCB socket operates at voltages up to 515V and supports a current rating of 5.7A per pin, making it suitable for a wide range of power and signal applications. It has a vertical orientation with through hole mount type and standard solder termination, ensuring secure and durable attachment to PCBs.

The socket is engineered for a broad operating temperature range from -55°C up to 125°C, allowing usage in harsh industrial settings. The contact tails measure 0.635 mm square, optimized for PC/104 embedded computing applications. It features a normal insertion force of 125 grams, balancing ease of assembly and solid electrical connection.

The socket can withstand up to 100 mating cycles, with a gold plating thickness of 10 microinches (0.25 μm), enhancing contact longevity and performance. This product is designed for use across electronics manufacturing, industrial automation, and other technical applications where reliable board-to-board connectivity is critical.

Constructed from high-quality black glass filled polyester housing. Phosphor bronze contacts with gold plating to resist corrosion. Vertical through hole mount style for secure PCB attachment. Rated for 5.7A current and 515V voltage operation.

Wide temperature range operation from -55°C to 125°C. Supports up to 100 mating cycles with durable gold contacts. Ideal for PC/104 and board-to-board connections in industrial electronics. Explore our extensive selection of PCB Sockets and connectors at EnvMart for reliable and precision electronic components suited to various industrial and commercial applications.
