HARWIN Datamate J-Tek Series Straight Panel PCB Socket, 42-Contact, 2 Row, 2 mm Pitch Crimp M80-4604242

HARWIN M80-4604242 Datamate J-Tek Series Straight Panel PCB Socket is a high reliability connector designed for demanding industrial, military, aerospace, and high-end commercial applications. This PCB socket features 42 female crimp contacts arranged in 2 rows with a 2 mm pitch, providing compact, robust, and secure connections.

The housing is constructed from polyphenylene sulphide (PPS) which offers excellent mechanical stability and resistance to harsh environments. The contact material is beryllium copper alloy, gold-plated to ensure superior electrical conductivity and corrosion resistance. The crimp termination with 4-finger contacts allows for reliable operation under extreme temperatures ranging from -55°C to 125°C and can withstand high vibration and shock loads.

This connector series is designed for panel mounting and offers a straight orientation in a board-to-board connector system. The connectors include fully shrouded housings with polarization to prevent mis-mating, and the jackscrews secure the connector in place for stable connections.

The product meets stringent military and industrial standards, including BS9525-F0033, MIL C 55302, and CEC 75101-008, making it suitable for critical communications and control systems. Typical applications include aerospace and aeronautics, military equipment, data and telecommunications networks, medical devices, handheld and industrial equipment, robotics, and oil and gas machinery.

The Datamate J-Tek series is engineered to offer longevity with high numbers of mating cycles without performance degradation, making it ideal for use in harsh and safety-critical environments.

Offers a compact 2mm pitch PCB socket with 42 female contacts and 2 rows. Housing is made from durable polyphenylene sulphide ensuring robust mechanical strength. Crimp contacts crafted from beryllium copper alloy with gold plating provide excellent conductivity and corrosion resistance.

Suitable for high vibration and shock environments with operating temperatures from -55°C to 125°C. Designed for panel mount with a straight orientation and board-to-board connection system. Rated for 12A current and 120V voltage for reliable electrical performance.

Incorporates polarization features and fully shrouded housing to prevent mis-mating. Ideal for aerospace, military, telecommunications, medical, robotics, industrial equipment, and oil & gas sectors. Complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 military and industry standards.
