Hirose FH33 1 mm Pitch 4 Way Straight Female FPC Connector, Solder, Surface Mount, 50V AC, 500mA Current FH33

Hirose FH33 1 mm Pitch 4 Way Straight Female FPC Connector, model FH33, is a high-quality surface mount solder connector designed for precise and reliable electrical connections in compact electronic devices. With a low profile height of 1.25 mm and mounting depth of only 2.5 mm, this connector helps minimize PCB footprint, making it ideal for densely packed applications.

The connector features 4 phosphor bronze contacts with gold plating to ensure excellent conductivity and corrosion resistance. It supports electrical ratings of 50V AC voltage and 500mA current, making it suitable for low-power signal transmissions. This FPC Connector incorporates a bottom-contact design and a straight orientation for ease of assembly and integration.

A key feature is the zero insertion force (ZIF) rotating actuator, which enables easy insertion and secure retention of the flexible printed circuit (FPC). The actuator provides a tactile click once fully closed, confirming proper locking and connection stability. The polyamide housing adds functional durability and environmental resistance.

The FH33 series operates reliably across a wide temperature range from -55°C to 85°C, ensuring stable performance in various environments. This connector accepts standard 0.3 mm thick FPC cables and is perfect for compact portable electronic equipment, personal mobile devices, and other applications requiring miniature connections with secure locking mechanisms.

Low profile height of 1.25 mm reduces space usage on PCBs. Gold-plated phosphor bronze contacts provide reliable signal transmission. Rotating one-touch ZIF actuator ensures easy FPC insertion and secure locking. Polyamide housing contributes to mechanical durability and environmental resistance.

Wide operating temperature range from -55°C to 85°C. Accepts standard 0.3 mm thick flexible printed circuits. Stable electrical characteristics at 50V AC and 500mA current. Straight orientation with bottom contacts for design flexibility.

Ideal for miniaturized portable and mobile electronic applications.

This Hirose FH33 connector is a reliable choice for high-density electronic circuit design, supporting efficient manufacturing and enhancing long-term device performance. Explore our extensive selection of FPC and electronic connectors to find complementary components for your projects at EnvMart.
