Molex 1 mm Pitch 4 Way Right Angle Female FPC Connector ZIF Bottom Contact 52271-0479
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50, 50V ac |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 500mA |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | 52271 |
| Termination Type | ZIF Bottom Contact |
| Maximum Operating Temperature | 85°C |
| Sub Type | Easy-On FFC/FPC Connector |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin Bismuth Alloy |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- Space-saving design ideal for tight packaging applications.
- Slide type actuator rotates 30° to ease FPC insertion.
- Phosphor bronze contacts plated with tin bismuth alloy ensure reliable conductivity.
- Nylon housing with locking mechanism provides durable strain relief.
- Rated for 50V AC voltage and 500mA current capacity.
- Suitable for operating temperatures from -40°C to 85°C.
- Right angle orientation with bottom contact positioning.
- Easy-On FFC/FPC connector subtype with ZIF termination.
Product Description
Molex 52271-0479 is a 1 mm pitch 4 Way Right Angle Female FPC Connector with Zero Insertion Force (ZIF) bottom contact designed for surface mount applications. This connector features a space-saving design making it ideal for usage in tight packaging environments.
The slide type actuator rotates 30 degrees allowing for easier insertion of the flexible printed circuit (FPC). The connector's movable contacts ensure secure contact retention even when the cable is pulled, providing reliability in electrical connections.
Contact material is phosphor bronze with tin bismuth alloy plating, enhancing conductivity and corrosion resistance. The nylon housing provides insulation and mechanical strength with an integrated locking mechanism for secure assembly. The right angle design of the connector is suited for low-profile mounting on printed circuit boards.
The connector operates at voltages up to 50V AC with a current rating of 500mA and accommodates a temperature range from -40°C to 85°C, making it suitable for various industrial and commercial applications.
Solder tabs on the base provide strain relief and firm PCB retention, ensuring long-term durability and performance. These connectors find applications in automotive navigation and audio systems, medical equipment, digital cameras, mobile phones, tablets, and GPS devices.
Space-saving design. ZIF for repeat cycling with minimal wear. Slide type actuator for easy insertion and secure connection. Phosphor bronze contacts with tin bismuth alloy plating. Nylon housing with locking mechanism. Right angle orientation with bottom contact position.
Operational voltage: 50V AC and current: 500mA. Operating temperature range: -40°C to 85°C. Solder tabs provide strain relief for PCB retention. Ideal for automotive, consumer electronics, and medical industries. Explore more electronic connectors and components in EnvMart’s extensive catalog designed to meet industrial and commercial application needs.
