TDK Through Hole EMC Filter B84110A0000A040 4A 250V AC/DC 60Hz Single Phase

Free Delivery in India | Lowest Global Shipping Charges

TDK Through Hole EMC Filter B84110A0000A040 4A 250V AC/DC 60Hz Single Phase



Category Power Line Filters Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	23mm
Length	56mm
Model	B84110A0000A040
Depth	30mm
Mount Type	Through Hole
Operating Frequency	60Hz
Series	B84110-A
Maximum Operating Temperature	100°C
Capacitance	4700pF
Minimum Operating Temperature	-25°C
Maximum Current	4A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac/dc
Inductance	2mH
Standards/Approvals	UL1283
Termination Style	Pin
Applications include	medium-performance SMPSUs, data systems, gambling machines

Key Features

Features a two-line filter suitable for medium-performance SMPSUs applications.
Plastic housing ensures durability and protection against environmental factors.
Provides high attenuation for effective electromagnetic interference suppression.
Capacitance rating is 4700pF with 2mH inductance for optimal filtering performance.
Compact dimensions with length 56mm, height 23mm, and depth 30mm for easy PCB mounting.
Termination style uses pin through-hole mounting for secure connections.
Operates reliably between -25°C and 100°C temperature ranges.
Leakage current is low at 369μA ensuring energy efficiency.

Product Description

TDK B84110A0000A040 Through Hole EMC Filter is a high-quality two-line filter designed for single-phase electrical systems. Rated for a maximum current of 4A and a maximum voltage of 250V AC/DC, it operates at a frequency of 60Hz. This filter features a plastic housing that provides durability and protection, making it suitable for various industrial and electronic applications.

The filter incorporates a capacitance of 4700pF and inductance of 2mH, offering high attenuation for electromagnetic interference. Its compact form factor measures 56mm in length, 23mm in height, and 30mm in depth, optimized for easy through-hole mounting using pin terminations.

Designed to perform effectively within a wide temperature range from -25°C to 100°C, the device has a low leakage current of 369μA, ensuring minimal energy wastage. It meets UL1283 standards, guaranteeing adherence to safety and performance guidelines.

Typical applications include medium-performance switched-mode power supplies (SMPSUs), data communication systems, and gambling machines where EMI filtering is crucial to maintain signal integrity and reduce noise interference.

Two-line filter designed for single-phase systems. Plastic housing offers robust protection. Compact dimensions facilitate easy PCB installation. High attenuation ensures EMI suppression. Wide operating temperature range for versatile applications.

Low leakage current enhances energy efficiency. Complies with UL1283 safety and quality standards. Ideal for medium-performance SMPSUs and data systems. Supports stable operation in gambling machines.
