TDK Flange EMC Filter, Screw 3 Phase, 50A, 520V AC, 50Hz/60Hz, B84143A0050R106

Free Delivery in India | Lowest Global Shipping Charges

TDK Flange EMC Filter, Screw 3 Phase, 50A, 520V AC, 50Hz/60Hz, B84143A0050R106



Category Power Line Filters Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	80mm
Length	217mm
Model	B84143A0050R106
Depth	84.5mm
Mount Type	Flange
Operating Frequency	50, 60Hz
Series	B84143A*R106
Maximum Operating Temperature	100°C
Number Of Stages	1
Resistance	1.1mΩ
Minimum Operating Temperature	-25°C
Maximum Current	50A
Number of Phases	3
Leakage Current	3.4mA
Maximum Voltage	520V ac
Standards/Approvals	UL 1283
Termination Style	Screw
Applications include	Frequency converters for motor drives (e.g. elevators, pumps, conveyor systems and HVAC systems), Power supplies, Textile machines, Packaging machines and Machine - tools

Key Features

Efficient suppression of electromagnetic interference in three-phase power lines.
Supports a maximum current of 50A and a maximum voltage of 520V AC.
Operates at 50Hz and 60Hz, suitable for industrial frequency converters.
Flange mount design for robust installation in control panels.
Screw termination style ensures secure electrical connections.
Compact metal case offers durability and easy integration.
Leakage current optimised at 3.4mA for safety compliance.
Certified to UL 1283 and IEC 60939 standards.

Product Description

The TDK B84143A0050R106 is a high-performance flange-mount EMC filter designed for three-phase power line applications, providing maximum suppression of electromagnetic interference. With its robust construction and compact metal case, this filter is engineered to deliver reliable performance in demanding industrial environments, including frequency converters for motor drives, elevators, HVAC systems, textile machinery, packaging machines, and machine tools.

Featuring a maximum current rating of 50A and a voltage capability up to 520V AC, the filter is suitable for applications requiring both high power and stringent EMC protection. Its operation covers both 50Hz and 60Hz frequencies, making it versatile for global industrial installations.

The B84143A0050R106 is designed with a flange mount for secure fixation and screw termination style for stable and hassle-free wiring in electrical panels. The filter’s single-stage configuration is optimised for long motor cables, and high insertion loss ensures efficient noise suppression even under full load conditions.

Leakage current of just 3.4mA helps maintain electrical safety. The product operates between -25°C and 100°C, with dimensions of 217mm length, 84.5mm depth, and 80mm in height, making it suitable for installation in space-constrained environments. Resistance of 1.1mΩ supports minimal voltage drop and high efficiency.

Compliant with UL 1283 and IEC 60939 standards, this EMC filter assures users of international certification and quality. Its IP20 rating confirms protection against solid objects, and it is optimised for industrial environments requiring reliable EMC solutions.

Efficient suppression of EMI for motor drives, power supplies, and industrial automation. Wide voltage and current capability ensures compatibility with heavy-duty equipment. Compact and durable enclosure for space-saving installation.

Safe, low leakage current and broad operating temperature range. Flange mount facilitates easy integration in control cabinets. International safety and EMC compliance for trusted operation.

Ideal for industries including construction, manufacturing, automation, and HVAC systems where power line EMC filtering is critical. Browse more TDK filters and related EMC solutions in the Power Line Filters category on EnvMart.
