Bourns DR334A Panel Mount Power Line Filter, 500 mA, 80V DC, Surface Mount, 1 Phase, Inductance 100μH,
Specifications
| Country of Origin | China |
|---|---|
| Brand | Bourns |
| Height | 3.6mm |
| Length | 9mm |
| Model | DR334A |
| Depth | 5.8mm |
| Packaging | Reel |
| Mount Type | Panel Mount |
| Operating Frequency | 10000Hz |
| Series | DR334A |
| Maximum Operating Temperature | 135°C |
| Minimum Operating Temperature | -40°C |
| Maximum Current | 500mA |
| Number of Phases | 1 |
| Maximum Voltage | 80V dc |
| Inductance | 100μH |
| Standards/Approvals | RoHS |
| Termination Style | Surface Mount |
Key Features
- Panel mount design for reliable installation.
- Maximum current rating of 500 mA ensures electrical stability.
- Supports voltage up to 80V DC for versatile electronic applications.
- Surface mount termination style for efficient PCB placement.
- Inductance of 100μH for effective filtering performance.
- Operates at a frequency of 10000Hz for wide EMI suppression range.
- Single-phase configuration tailored for modern circuits.
- Operating temperature range from -40°C to 135°C for robust durability.
Product Description
Bourns DR334A-113BE Panel Mount Power Line Filter is engineered for efficient suppression of electromagnetic interference in electronic circuits. With a maximum current capacity of 500 mA and a rated voltage of 80V DC, the DR334A-113BE model is designed for one-phase applications with surface mount installation.
This model incorporates an inductance of 100μH and operates at a frequency up to 10000Hz, offering a broad EMI suppression range suitable for modern electronic devices. Featuring bifilar windings and a toroid core, it provides self-shielding and low radiation, making it ideal for sensitive environments.
The filter supports reel packaging and surface mount termination, allowing for seamless integration onto printed circuit boards in industrial, laboratory, and commercial electronics applications. Its robust construction includes an enamelled copper wire for enhanced conductivity and durability.
The operating temperature range from -40°C to 135°C ensures reliable performance across diverse climates, while compact dimensions - 9mm in length, 3.6mm height, and 5.8mm depth - suit space-constrained builds.
Panel mount design ensures ease of installation in device enclosures. Current rating of 500 mA supports stable operation in low-to-mid power applications. Voltage rating up to 80V DC accommodates multiple circuit designs.
Inductance and EMI suppression performance enable compliance with stringent standards. Single phase configuration optimizes for typical electronic and industrial uses. Temperature resilience enhances reliability in harsh environments.
RoHS certification guarantees environmentally conscious manufacturing.
This filter is AEC-Q200 compliant, suitable for sectors such as electronics manufacturing, power supplies, instrumentation, laboratory equipment, and communication devices. It is especially tailored for designers seeking reliable EMI protection and compact, surface-mountable form factors.
Browse more Bourns Power Line Filters in electronics and component categories on EnvMart for high-quality, certified EMI filtering solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this model is 500 mA, ensuring stable operation in low-to-mid power applications.
It supports a maximum voltage of 80V DC, making it suitable for various electronic circuit designs.
The inductance of the DR334A is 100μH, which contributes to its effective EMI suppression performance.
This model operates at a frequency of up to 10000Hz, providing a broad range for EMI suppression.
The dimensions are 9mm in length, 3.6mm in height, and 5.8mm in depth, making it suitable for compact installations.
It features a panel mount design, which ensures reliable installation in device enclosures.
The operating temperature range is from -40°C to 135°C, allowing for reliable performance in diverse climates.
This model utilizes a surface mount termination style, facilitating efficient placement on printed circuit boards.
Yes, it is RoHS certified, ensuring environmentally conscious manufacturing practices.
It is suitable for use in electronics manufacturing, power supplies, instrumentation, laboratory equipment, and communication devices.
The filter is packaged in reel format, which supports seamless integration during assembly processes.
This model is designed for single-phase applications, optimizing it for typical electronic and industrial uses.
