Molex PicoBlade Series Right Angle Through Hole PCB Header 5 Contact 1.25mm Pitch 1 Row Shrouded 53048-0510

Free Delivery in India | Lowest Global Shipping Charges

Molex PicoBlade Series Right Angle Through Hole PCB Header 5 Contact 1.25mm Pitch 1 Row Shrouded 53048-0510

Name: Molex PicoBlade Series Right Angle Through Hole PCB Header 5 Contact 1.25mm Pitch 1 Row Shrouded 53048-0510
Brand: Molex
SKU: 186456
Price: 0.67 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	Korea
Voltage	125V
Brand	Molex
Orientation	Right Angle
Current	1A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Phosphor Bronze
Series	PicoBlade
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	1.25mm
Contact Plating	Tin
Number of Contacts	5
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	2.3mm

Key Features

Part of the PicoBlade Series suitable for compact electronic assemblies.
Features 1 row with 5 male phosphor bronze contacts for efficient conductivity.
Solder termination with tin-plated contacts for corrosion resistance.
Operates reliably within -40°C to 85°C temperature range.
Rated for 1A current at 125V voltage with a 2.3 mm tail pin length.
Right-angle orientation supports tight PCB layouts and compact designs.
Shrouded housing prevents misalignment and accidental disconnections during use.
Constructed from durable nylon housing material for electrical insulation.

Product Description

Molex 53048-0510 PicoBlade Series Right Angle Through Hole PCB Header is engineered for efficient wire-to-board connections in electronic devices, offering 5 contacts with 1.25 mm pitch in a single row configuration. Its shrouded design and right angle orientation allow for compact PCB assembly layouts while ensuring a secure, reliable connection.

Constructed with high-quality phosphor bronze contacts plated with tin, this PCB header ensures excellent electrical conductivity and corrosion resistance. The nylon housing provides robust insulation and protection, contributing to product longevity. The solder termination type with a 2.3 mm tail pin length allows easy soldering to PCB boards.

The component operates reliably within a wide temperature range from -40°C to 85°C and is rated at 1A current and 125V, making it suitable for various industrial, consumer electronics, and automation control applications. The shroud protects contacts from misalignment and accidental disconnections, enhancing connection stability in environments with vibration or movement.

This connector is recommended for use with PCBs of 0.80 mm thickness for proper fit and performance. Its locking mechanism ensures secure mated connections to minimize operational disruptions.

Part of the PicoBlade Series suitable for compact electronic assemblies. 5 male phosphor bronze contacts plated with tin for reliable conductivity. Nylon housing for electrical insulation and mechanical stability. Right-angle, shrouded design for compact and secure PCB connections.

Rated 1A current at 125V voltage for safe operation. Operating temperature range: -40°C to 85°C. Solder termination with 2.3 mm tail pin length. Compatible with Molex wire-to-wire connectors. Recommended PCB thickness: 0.80 mm.

Locking mechanism for secure mating and anti-disconnection assurance.

This Molex PCB Header is ideal for electronics manufacturing, automation systems, and consumer device PCB assemblies where reliable, high-quality wire-to-board connections are needed. Explore more Molex connectors and related components in the Electronics & Electricals category on EnvMart.
