Vishay Bridge Rectifier, 600 V 420 A, 4-Pin Single VS-GBPC2506A

Free Delivery in India | Lowest Global Shipping Charges

Vishay Bridge Rectifier, 600 V 420 A, 4-Pin Single VS-GBPC2506A

Name: Vishay Bridge Rectifier, 600 V 420 A, 4-Pin Single VS-GBPC2506A
Brand: Vishay
SKU: 182953
Price: 5.18 USD
Availability: InStock



Category Bridge Rectifier Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	7.7mm
Length	28.6mm
Model	VS-GBPC2506A
Width	28.6mm
Mount Type	Screw
Series	VS-GBPC
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	GBPC
Minimum Operating Temperature	-55°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	600V
Peak Reverse Current Ir	5μA
Peak Non-Repetitive Forward Surge Current Ifsm	420A
Forward Current If	25A
Peak Forward Voltage Vf	1.1V
Universal, 3-way terminals	Push-on, wrap around or solder
Vishay Bridge Rectifier, 400 V 420 A, 4-Pin SingleBrand	Vishay

Key Features

The product operates with a peak reverse repetitive voltage of 600 volts ensuring reliability in high voltage environments.
It can handle a forward current of 25 amps and surge currents up to 420 amps for transient conditions.
Designed with a high thermal conductivity package for excellent power-to-volume ratio and enhanced heat dissipation.
Features universal 3-way terminals suitable for push-on, wrap-around, or soldering connections for flexible mounting.
Compact dimensions of 28.6 mm length, 28.6 mm width, and 7.7 mm height make it suitable for space-constrained installations.
Operational temperature ranges between -55°C to 150°C for use in a wide range of thermal environments.
The package type is GBPC with screw mount type for secure and stable installation.
Peak forward voltage is 1.1 V, indicating low power losses during conduction.

Product Description

Vishay VS-GBPC2506A Bridge Rectifier is a high-performance semiconductor device designed for converting alternating current (AC) input into direct current (DC) output through full-wave rectification.

This 4-pin single-phase bridge rectifier operates at a peak reverse repetitive voltage of 600 V and supports a forward current of 25 A with surge current handling capacity of 420 A, making it well-suited for demanding industrial and electronic power supply applications.

The package features a GBPC type design with a screw mount capability, delivering high thermal conductivity and an electrically insulated case, which results in excellent power-to-volume performance and reliable thermal management.

Its universal 3-way terminal configuration allows flexible installation methods, including push-on, wrap-around, or soldering connections, enhancing versatility in various electronic component assemblies.

With dimensions of 28.6 mm length, 28.6 mm width, and 7.7 mm height, the device is compact yet robust, maintaining operational functionality from -55°C to 150°C ambient temperatures, suitable for a wide array of environments including industrial, manufacturing, and HVAC systems.

The product features a peak forward voltage of 1.1 V to minimize energy losses during conduction. Its low peak reverse current of 5 μA contributes to high efficiency and reduced leakage during inactive cycles. The rectifier meets UL E54214 certification standards, ensuring compliance with recognized safety and quality benchmarks.

The high surge current capacity makes it reliable for transient overload scenarios in power electronics. This bridge rectifier is commonly used in power supplies, control systems, and industrial electronic devices requiring efficient rectification.

For technicians, engineers, and industrial users seeking dependable Bridge Rectifiers, the Vishay VS-GBPC2506A model presents a compact, robust, and thermally efficient solution. It is ideal for applications demanding high voltage and current capabilities combined with flexible mounting options.
