Vishay 200 V 70 A Switching Diode 2-Pin DO-203AB VS-70HF20
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 17.4mm |
| Brand | Vishay |
| Height | 22.9mm |
| Length | 20.08mm |
| Model | VS-70HF20 |
| Width | 17.4mm |
| Mount Type | Screw |
| Series | VS-70HF |
| Maximum Operating Temperature | 180°C |
| Package Type | DO-203AB |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 70A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Stud Cathode |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 15mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1.3kA |
| Maximum Forward Voltage Vf | 1.35V |
| Vishay 400 V 70 A Diode Switching 2-Pin DO-203ABBrand | Vishay |
Key Features
- The diode uses a stud cathode with screw mounting for secure installation.
- It supports a peak non-repetitive forward surge current up to 1.3 kA.
- Operating temperature ranges from -65°C to 180°C for reliability in harsh environments.
- Features a maximum forward voltage of 1.35 V ensuring efficient conduction.
- Compact dimensions of approximately 22.9 mm height, 20.08 mm length, and 17.4 mm diameter.
- Designed for standard recovery rectifier applications requiring durable switching power diodes.
- 2-pin configuration facilitates easy integration in power electronic circuits.
- Peak reverse current is limited to 15 mA ensuring stability at rated voltages.
Product Description
Vishay VS-70HF20 is a high-performance switching diode featuring a maximum continuous forward current of 70 A and a peak reverse repetitive voltage of 200 V. Packaged in a 2-pin DO-203AB stud cathode style with screw mounting, it is engineered for power rectification and switching applications in industrial and electronic systems.
This diode supports a peak non-repetitive forward surge current of 1.3 kA and offers a maximum forward voltage of 1.35 V, providing efficient conduction with minimal voltage loss. It operates reliably between temperatures of -65°C and 180°C, making it suitable for demanding environments.
Its robust package dimensions - 22.9 mm height, 20.08 mm length, and 17.4 mm diameter - allow for secure installation and heat dissipation. The low peak reverse current of 15 mA ensures excellent stability during operation.
These features make the Vishay VS-70HF20 diode ideal for use in industrial power supplies, rectifiers, switching circuits, and electronic devices requiring durable and efficient diode components.
The diode uses a stud cathode with screw mounting for reliable fixation. Supports high surge current of 1.3 kA for transient events. Wide operating temperature range from -65°C to 180°C ensures durability. Compact 2-pin DO-203AB package for easy circuit integration.
Low forward voltage drop of 1.35 V for efficient power management. Peak reverse current limited to 15 mA for stable operation. Designed as a standard recovery rectifier for switching applications. This diode is widely used in industrial automation, power electronics, manufacturing equipment, and electronic component assemblies.
Explore more Semiconductors and rectifiers on EnvMart for your industrial and laboratory requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay VS-70HF20 diode is 70 A.
This model has a peak reverse repetitive voltage rating of 200 V.
It supports a peak non-repetitive forward surge current of 1.3 kA.
The operating temperature range for the Vishay VS-70HF20 is from -65°C to 180°C.
The maximum forward voltage drop is 1.35 V, ensuring efficient conduction.
The diode has a height of 22.9 mm, a length of 20.08 mm, and a diameter of 17.4 mm.
It uses a screw mounting method for secure installation.
The VS-70HF20 features a stud cathode configuration.
The peak reverse current is limited to 15 mA, ensuring stability at rated voltages.
It is designed for standard recovery rectifier applications requiring durable switching power diodes.
The country of origin for this diode is India.
This model has a 2-pin configuration, facilitating easy integration into power electronic circuits.
