Broadcom 8 Dot Matrix LED Display 8 Characters Green Orange Yellow Red 7.5mcd 4.6mm HDSP-2533

Broadcom HDSP-2533 8 Dot Matrix LED Display is a high-quality alphanumeric display designed for multiple industrial and electronic applications. It features 8 characters arranged in a 5 by 7 dot matrix format, capable of displaying all 128 ASCII characters and up to 16 user-programmable symbols. The display employs a green, orange, yellow, and red LED color range with a typical luminous intensity of 7.5mcd and a character height of 4.6mm, packed in a compact 30-pin DIP through-hole package.

The onboard CMOS integrated circuit supports a microprocessor bus interface, simplifying integration with various control boards. Seven distinct brightness levels enable precise control of display intensity while conserving power. This display module is well-suited for use in industrial instrumentation, computer peripherals, portable data entry devices, telecommunications equipment, and testing devices, offering reliable readability across a wide ambient temperature range from -40°C to +85°C.

Its robust design and RoHS compliance make it suitable for environmentally conscious manufacturing and assembly practices. The black face color enhances the visibility of characters, even in challenging lighting environments. The display's compact dimensions and through-hole mount type allow easy and secure installation on standard printed circuit boards.

The display uses a 5 x 7 dot matrix for alphanumeric characters. Onboard CMOS IC decodes 128 ASCII characters stored in permanent ROM. Supports 16 programmable symbols stored in RAM for custom display needs. Offers seven levels of brightness adjustment to optimize power and visibility.

Packaged in a 30-pin DIP, designed for through-hole mounting. Operates reliably from -40°C to 85°C, suitable for harsh environments. Luminous intensity of 7.5mcd delivers clear, bright display output. Standard microprocessor bus interface enables flexible control.

Applications include industrial devices, telecommunications, and test equipment. Complies with environmental RoHS directives.

This Broadcom LED display is recognized for its versatility and robust performance, fulfilling demanding industrial and commercial display requirements. Explore more components in the LED Displays category at EnvMart to complement your electronic system design.
