Molex Micro-Latch Series Right Angle Through Hole PCB Header, 2 Contacts, 2 mm Pitch, 1 Row, Shrouded 53254-0270
Specifications
| Country of Origin | Malaysia |
|---|---|
| Voltage | 125V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 2A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Micro-Latch |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Standards/Approvals | UL E29179 |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
| Mating Pin Length | 2mm |
Key Features
- Features a right angle orientation for PCB mounting.
- Shrouded design for enhanced protection against accidental contact.
- Constructed with a durable nylon housing material.
- Brass contacts plated with tin for reliable conductivity.
- Rated for 2A current and 125V voltage operation.
- Suitable for operating temperatures from -40°C to +105°C.
- Termination type is solder with through hole mounting.
- Tail pin length measures 3.5 mm with mating pin length of 2 mm.
Product Description
Molex 53254-0270 is a Micro-Latch Series Right Angle Through Hole PCB Header that offers dependable wire-to-board connectivity with a compact footprint. The component features 2 contacts arranged in a single row with 2 mm pitch, optimized for electronic assemblies requiring efficient space utilization and secure connections.
This PCB header is constructed with a robust nylon housing that provides mechanical strength and electrical insulation, paired with brass contacts plated with tin to ensure excellent conductivity and corrosion resistance. The shrouded design safeguards the contacts and minimizes risks of accidental shorts or damage.
Designed for through hole mounting, this connector terminates with solder, ensuring stable mechanical and electrical bonds. It is rated for 2 amperes of current and can withstand voltages up to 125V, making it suitable for a wide range of electronic equipment operating environments.
The product supports an operating temperature range from -40°C to +105°C, which allows use in industrial, consumer electronics, automotive, and communications devices. The tail pin length of 3.5 mm and mating pin length of 2 mm facilitate compatibility with various mating connectors and PCB layouts.
Certified to UL E29179 standards, the connector ensures compliance with recognized safety and quality benchmarks. This Molex Micro-Latch PCB header is ideal for applications in industrial instrumentation, control systems, telecommunications, and general electronics manufacturing where reliable, compact, and robust board-to-wire connections are necessary.
Features a right angle orientation for PCB mounting. Shrouded design protects contacts. Durable nylon housing material. Brass contacts with tin plating. Rated for 2A current and 125V voltage. Operating temperature range: -40°C to +105°C.
Through hole solder termination. UL E29179 certified. Tail pin length: 3.5 mm; mating pin length: 2 mm. Explore more connectors and PCB Headers in the Electronics & Electricals category at EnvMart for comprehensive component sourcing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header is rated for 2A current and can withstand voltages up to 125V.
It operates within a temperature range of -40°C to +105°C, making it suitable for various environments.
The housing is made of durable nylon, while the contacts are brass with tin plating for reliable conductivity.
This model features 2 contacts arranged in a single row with a 2 mm pitch.
It utilizes through hole mounting with solder termination for secure connections.
The tail pin length measures 3.5 mm, while the mating pin length is 2 mm.
Yes, it is certified to UL E29179 standards, ensuring compliance with recognized safety and quality benchmarks.
This connector features a right angle orientation for PCB mounting.
It is designed as a wire-to-board connector system, facilitating reliable connections between wires and PCBs.
It is ideal for applications in industrial instrumentation, control systems, telecommunications, and general electronics manufacturing.
The contacts have a pitch of 2 mm, with a total of 2 contacts in a single row.
This model features male contacts, which are standard for many PCB applications.
