Molex 502584 Series Vertical Surface PCB Socket, 2-Contact, 1 Row, 1.5 mm Pitch, Surface Mount 502584-0270
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 100V |
| Brand | Molex |
| Orientation | Vertical |
| Current | 2A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | 502584 |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Sub Type | Wire-to-Board |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.5mm |
| Standards/Approvals | CHINA RoHS, EU RoHS |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Connector System | Wire-to-Board |
Key Features
- Rated for 100V voltage and 2A current for reliable electrical performance.
- Constructed with copper alloy contacts plated with tin for durability and corrosion resistance.
- Designed for a vertical orientation and wire-to-board connector system.
- Operational temperature range from -40°C to 105°C enables use in varied environments.
- Compact 1.5 mm pitch and single row design supports high-density PCB layouts.
- Surface mount termination type supports modern PCB assembly processes.
- Beige-colored body enhances visibility and identification on printed circuit boards.
- Compliance with CHINA RoHS and EU RoHS standards ensures environmental safety.
Product Description
Molex 502584-0270 is a vertical surface mount PCB socket featuring 2 contacts arranged in a single row with a 1.5 mm pitch. This compact connector operates at 100 volts and 2 amperes, providing stable and reliable electrical connections for electronic applications.
Constructed from copper alloy contacts with tin plating, it delivers excellent conductivity and corrosion resistance. The socket is part of the 502584 series and utilizes surface mount termination for streamlined PCB assembly.
Its vertical orientation and wire-to-board connector system make it ideal for compact PCB layouts requiring secure and efficient connections. The device operates reliably within a temperature range of -40°C to 105°C, supporting use in various industrial, electronic, and commercial environments.
The beige-colored body aids in identification on circuit boards, and the product complies with both China RoHS and EU RoHS environmental standards for safe usage.
This PCB socket is manufactured in Japan, ensuring high manufacturing standards and quality assurance. It is suitable for applications in electronics components, power and connectors, industrial tools, and equipment sectors.
Rated at 100V and 2A for assured electrical performance. Copper alloy contacts with tin plating for durability. Vertical orientation, single row configuration with 1.5 mm pitch. Surface mount design for modern PCB assembly.
Operating temperature from -40°C to +105°C. RoHS compliant for environmental safety. Beige colored body for PCB visibility. Wire-to-board connector system supporting diverse applications. Manufactured in Japan for quality assurance.
Explore Molex components and additional PCB Sockets at EnvMart for reliable connector solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket is rated for 100V voltage and 2A current, providing reliable electrical performance for various applications.
The operating temperature range for this model is from -40°C to 105°C, making it suitable for use in diverse environments.
The contacts of this socket have a pitch size of 1.5 mm, which supports high-density PCB layouts.
This PCB socket features 2 contacts arranged in a single row configuration.
The contacts are constructed from copper alloy and are plated with tin for enhanced conductivity and corrosion resistance.
This model utilizes surface mount termination, which is suitable for modern PCB assembly processes.
The socket is designed for vertical orientation, making it ideal for wire-to-board connections in compact layouts.
Yes, it complies with CHINA RoHS and EU RoHS standards, ensuring environmental safety.
This PCB socket is manufactured in Japan, ensuring high manufacturing standards and quality assurance.
This model features a wire-to-board connector system, which supports secure and efficient connections.
The body of this PCB socket is beige, which enhances visibility and identification on printed circuit boards.
This socket has a single row configuration, which is typical for compact PCB designs.
