| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTA114EQB-QZ |
| Mount Type | Surface |
| Series | PDTA114E |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1110D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -50V |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | -10V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | -100mA |
| Transistor Configuration | PNP |
Nexperia PDTA114EQB-QZ resistor-equipped transistor is a high-quality PNP transistor designed for efficient switching and signal amplification. It supports a maximum DC collector current of -100 mA and a collector-emitter voltage of -50 V. Featuring a compact 3-pin DFN1110D-3 plastic leadless surface mount package with side-wettable flanks, this device enables low profile assembly with a package height of only 0.5 mm.
The built-in resistors simplify circuitry, reducing the number of external components required which leads to lower component count and reduces pick and place cost for automated assembly lines. Its wide operating temperature range from -55°C to 150°C and compliance to RoHS and automotive AEC-Q101 standards make it highly suitable for automotive and industrial digital applications.
Applications include controlling IC inputs, switching loads in digital circuits, and serving as a cost-effective replacement for the BC857 series. The device's surface mount design supports automatic optical inspection (AOI) of solder joints for quality assurance.
Compact 3-pin DFN1110D-3 surface mount package. Maximum DC collector current: -100 mA. Maximum collector-emitter voltage: -50 V. Maximum emitter base voltage: -10 V. Operating temperature range: -55°C to 150°C. Built-in resistors reduce external components.
RoHS compliant and AEC-Q101 certified. Suitable for automotive, industrial, and digital switching applications.
Choose the Nexperia PDTA114EQB-QZ transistor for reliable performance in compact, cost-sensitive electronic designs. Explore EnvMart for extensive semiconductor solutions and related electronic components.
