| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTA124EQBZ |
| Mount Type | Surface |
| Series | PDTA124E |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1110D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -50V |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | -10V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | -100mA |
| Transistor Configuration | PNP |
Nexperia PDTA124EQBZ resistor-equipped PNP transistor is designed for digital and switching applications requiring compact size and efficient performance. Featuring a maximum DC collector current of 100 mA and a collector-emitter voltage rating of 50 V, this transistor suits a variety of industrial and commercial electronic circuits.
Packaged in an ultra-small DFN1110D-3 leadless surface-mounted device with side-wettable flanks, the transistor supports automated optical inspection processes and assembly lines, reducing manufacturing costs and component counts through its integrated resistors.
Its low package height of 0.5 mm enables slim PCB designs. The device is suitable as a cost-effective alternative to the BC857 series for digital circuits, switching loads, and controlling integrated circuit inputs.
The transistor maintains stable operation across a wide temperature range from -55°C to 150°C and complies with RoHS environmental standards and the automotive-grade AEC-Q101 standard, making it suitable for demanding industrial and automotive environments.
Supports a maximum DC collector current of 100 mA. Maximum collector to emitter voltage is 50 V for reliable switching. Plastic package with side-wettable flanks allows for automated assembly and solder inspection. Built-in resistors reduce external component requirements and assembly steps.
3-pin DFN1110D-3 package supports compact, surface-mount PCB layouts. Ideal for digital applications including signal switching and logic circuits. Compliant with RoHS and AEC-Q101 automotive standards. Wide operating temperature range from -55°C to 150°C ensures robust performance.
This transistor is well-suited for use in industrial electronics, digital system designs, communications equipment, and automotive controls. Its compact footprint and integrated resistor functionality lower system cost while enhancing reliability.
Explore more transistor solutions and Bipolar Transistors in the Nexperia series available at EnvMart for professional and industrial electronic design needs.
