Vishay MKP1848Se DC-Link Polypropylene Film Capacitor 50 μF 700 V dc 10% Tolerance Through Hole MKP1848Se

Vishay MKP1848Se DC-Link Polypropylene Film Capacitor, model MKP1848Se, provides a robust solution for demanding electronics applications requiring stability and reliability at 50 μF capacitance and 700 V DC rated voltage. This through-hole mounted capacitor features a metallized polypropylene film dielectric that offers excellent electrical characteristics including low equivalent series resistance (ESR) of 4mΩ and a dissipation factor of only 0.015%, enabling high performance in power electronics and DC link circuits.

Constructed for a broad operating temperature range from -40°C up to 105°C, and complying with IEC 61071 and AEC-Q200 automotive standards, this capacitor assures durability and consistent function in both industrial and automotive environments. The device’s lead pitch of 52.5 mm with six pins and lead length of 6 mm facilitates secure PCB installation. The capacitor is housed in a flame-retardant plastic case measuring 57.5 mm by 70 mm by 24 mm, ensuring safety and mechanical protection.

Its design featuring low inductance wound cell elements results in high ripple current handling capability critical for applications such as solar inverters, electric vehicles, and power conversion systems. The tinned wire terminals aid in reliable soldering and electrical connection.

This capacitor utilizes polypropylene film dielectric for enhanced electrical stability. It has low equivalent series resistance (4mΩ) and low dissipation factor (0.015%) ensuring efficient performance. Rated for operation between -40°C and 105°C with compliance to IEC 61071 and AEC-Q200 automotive standards.

Lead pitch measures 52.5 mm, with 6 pins and 6 mm lead length for secure PCB mounting. Encased in a flame-retardant plastic package, measuring 57.5 mm in length, 70 mm in width, and 24 mm in height. Suitable for DC-Link applications needing high ripple current capability and low inductance.

This capacitor is ideal for industrial power electronics, automotive systems, laboratory equipment, telecommunications, and other precision applications requiring high stability and reliability. The product is manufactured in Portugal and delivered as a new component ready for integration.

Explore more high-quality Film Capacitors and related electronic components at EnvMart for reliable and efficient electronic system design requirements.
