Epson 27.12 MHz Crystal Unit Surface Mount Technology ±15 ppm Frequency Tolerance 4-Pin SMT Package Q22FA1280037412

Epson Q22FA1280037412 Crystal Unit is a high-precision surface mount crystal oscillator designed to provide stable frequency output at 27.12 MHz frequency, with ±15 ppm tolerance. It is built to support applications requiring strict timing accuracy such as mobile communication devices, wireless modules including Bluetooth and WLAN, and ISM band radios. Its compact SMT package allows for integration in densely packed electronic assemblies.

The crystal unit supports a load capacitance of 6 pF and incorporates a 4-pin connection for reliable electrical contacts. Its dimensions are optimized with a length of 2 mm, width of 1.6 mm, and height of 0.5 mm. This crystalline component is RoHS compliant and lead-free, aligning with environmental and industrial standards.

Operating within a temperature range of -40°C to +85°C, this product remains stable and dependable in varied industrial and commercial environments. The frequency stability of ±15 ppm ensures minimal deviation to maintain consistent clock timing for MPU and communication systems. The series resistance of 60 Ω enables efficient oscillation and signal quality.

Crystal units from the Epson FA-128 series cover a nominal frequency range from 16 MHz to 54 MHz, and this particular model is tailored for the 27.12 MHz band suitable for a variety of timing applications. The crystal is packaged on tape and reel to support high-volume, automated manufacturing processes. This combination of features makes the Epson Q22FA1280037412 suitable for implementation in electronic manufacturing requiring mass production and high reliability.

This crystal unit operates with a load capacitance of 6 pF suitable for SMT applications. The package type is SMT with tape and reel packaging facilitating automated PCB assembly. It features a 4-pin configuration with compact dimensions of 2 mm length, 1.6 mm width, and 0.5 mm height.

The frequency stability and tolerance are ±15 ppm ensuring reliable timing accuracy. Operating temperature ranges from -40°C to 85°C, suitable for industrial environments. Series resistance is specified at 60 Ω, supporting efficient oscillation performance.

The crystal series is Q22FA, RoHS compliant, and free from lead content. The crystal unit has applications in mobile phones, Bluetooth, WLAN, ISM band radios, and MPU clocks.
