Epson 16 MHz Crystal Unit ±10 ppm TSX-3225 Surface Mount 4-Pin 3.2x2.5x0.6 mm X1E000021011312

Free Delivery in India | Lowest Global Shipping Charges

Epson 16 MHz Crystal Unit ±10 ppm TSX-3225 Surface Mount 4-Pin 3.2x2.5x0.6 mm X1E000021011312

Name: Epson 16 MHz Crystal Unit ±10 ppm TSX-3225 Surface Mount 4-Pin 3.2x2.5x0.6 mm X1E000021011312
Brand: Epson
SKU: 136073
Price: 2.28 USD
Availability: InStock



Category Crystal Units Brand Epson Condition New

Specifications

Country of Origin	India
Frequency range	16 MHz to 48 MHz
Brand	Epson
Height	0.6mm
Length	3.2mm
Model	X1E000021011312
Width	2.5mm
Mount Type	Surface
Series	TSX3225
Maximum Operating Temperature	85°C
Package Type	TSX-3225
Minimum Operating Temperature	-40°C
Interfaces	LAN ISM band radio, Clock for MPU
External Dimensions	3.2 x 2.5 x 0.6 mm
Standards/Approvals	REACH, RoHS
Pin Count	4
Standard Frequency	16MHz
Load Capacitance	10pF
Series Resistance	60Ω
Overtone order	Fundamental

Key Features

Standard frequency of 16 MHz with ±10 ppm tolerance.
Surface mount package type TSX-3225 with dimensions 3.2 x 2.5 x 0.6 mm.
4-pin configuration for stable electrical connectivity.
Load capacitance of 10 pF optimized for oscillator circuits.
Operating temperature range from -40°C to 85°C suitable for industrial use.
Series resistance of 60 Ω ensuring efficient signal quality.
Fundamental overtone order for reliable frequency generation.
Ideal for mobile phones, Bluetooth, WLAN ISM band radios, and MPU clocks.

Product Description

Epson X1E000021011312 is a high-precision 16 MHz crystal unit designed for surface mount applications with a compact TSX-3225 package measuring 3.2 x 2.5 x 0.6 mm. Featuring a ±10 ppm frequency tolerance, this 4-pin crystal unit provides reliable and stable oscillation critical for timing circuits in modern electronic devices.

The crystal unit supports a load capacitance of 10 pF and fundamental overtone order operation, making it suitable for oscillator circuits requiring consistent frequency control. It is capable of operating across a wide temperature range from -40°C to 85°C, allowing deployment in harsh industrial and commercial environments.

Its series resistance of 60 Ω ensures signal integrity, while the surface mount package facilitates efficient PCB assembly and space-saving design. This crystal unit is ideal for use in applications such as mobile phones, Bluetooth modules, WLAN ISM band radios, and MPU clock generation.

Compliance with international environmental standards REACH and RoHS confirms the product's eco-friendly manufacturing processes and materials, suitable for sustainable production requirements.

Standard frequency of 16 MHz with ±10 ppm tolerance. Surface mount TSX-3225 package with 4 pins and dimensions 3.2 x 2.5 x 0.6 mm. Load capacitance specified at 10 pF. Operating temperature range from -40°C up to 85°C. Series resistance rated at 60 Ω.

Fundamental overtone order operation. Applications in mobile and wireless communications equipment. Certified compliant with REACH and RoHS standards. Explore more electronic components and high-quality Crystal Units at EnvMart for your industrial and manufacturing needs.
