Epson 125MHz XO Oscillator ±50 ppm CMOS 4-Pin Surface Mount Q3309CA40006212

Free Delivery in India | Lowest Global Shipping Charges

Epson 125MHz XO Oscillator ±50 ppm CMOS 4-Pin Surface Mount Q3309CA40006212

Name: Epson 125MHz XO Oscillator ±50 ppm CMOS 4-Pin Surface Mount Q3309CA40006212
Brand: Epson
SKU: 334019
Price: 8.21 USD
Availability: InStock



Category Oscillator Brand Epson Condition New

Specifications

Country of Origin	India
Brand	Epson
Height	1.4mm
Length	7mm
Model	Q3309CA40006212
Width	5mm
Mount Type	Through Hole, Surface
Series	SG-8002
Maximum Operating Temperature	70°C
Output Frequency	125MHz
Package Type	Surface Mount
Minimum Operating Temperature	-20°C
Standards/Approvals	EU RoHS, ISO9001, ISO/TS 16949, ISO 14001
Pin Count	4
Automotive Standard	ISO/TS 16949
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	2.7V
Oscillator Type	XO
Output Level	CMOS

Key Features

Output frequency of 125MHz suitable for precision timing applications.
CMOS output level with a minimum supply voltage of 2.7V and maximum of 5.5V.
Compact ceramic package measuring 7mm length, 5mm width, and 1.4mm height.
Wide operating temperature range from -20°C to 70°C for various environments.
Mountable through hole or surface mount with 4 pins for easy PCB integration.
Complies with EU RoHS and quality standards ISO9001, ISO/TS 16949, and ISO 14001.
Part of the SG-8002 series designed for automotive and industrial applications.

Product Description

Epson Q3309CA40006212 125MHz XO Oscillator is a high-precision programmable crystal oscillator with PPL technology housed in a ceramic casing. It is designed for use in industrial, automotive, and electronic applications requiring stable frequency outputs.

This 4-pin surface mount oscillator delivers a stable 125MHz output frequency with ±50 ppm frequency stability. It features a CMOS output level compatible with low power embedded systems and microcontrollers.

The oscillator operates across a wide supply voltage range from 2.7V to 5.5V, making it versatile for various power environments. Its operating temperature range from -20°C to 70°C enables reliable performance in diverse climates and industrial conditions.

The device's ceramic 7mm by 5mm footprint and 1.4mm height allow for compact PCB layouts, with mount options including through hole and surface mount methods for flexible assembly.

Compliant with EU RoHS directives and quality certifications ISO9001, ISO/TS 16949, and ISO 14001, it meets stringent environmental and process standards.

The SG-8002 series oscillator is optimized for automotive systems and industrial instruments requiring precision timing. Common applications include telecommunications equipment, industrial control, instrumentation, and automotive electronics.

Output frequency of 125MHz suitable for precision timing applications. Frequency stability of ±50 parts per million ensures reliable signal accuracy. CMOS output level with a minimum supply voltage of 2.7V and maximum of 5.5V.

Compact ceramic package measuring 7mm length, 5mm width, and 1.4mm height. Wide operating temperature range from -20°C to 70°C for various environments. Mountable through hole or surface mount with 4 pins for easy PCB integration.

Complies with EU RoHS and quality standards ISO9001, ISO/TS 16949, and ISO 14001. Part of the SG-8002 series designed for automotive and industrial applications.

Select Epson crystal Oscillators for reliable industrial, automotive, telecommunications, and commercial electronics projects. Explore EnvMart for an extensive range of industrial electronic components from trusted global brands like Epson.
