RS PRO Desktop Spectrum Analyser 3kHz Bandwidth, 150kHz-3GHz Frequency Range, 5.6 in TFT LCD ISA-730, ISP-730

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Desktop Spectrum Analyser 3kHz Bandwidth, 150kHz-3GHz Frequency Range, 5.6 in TFT LCD ISA-730, ISP-730

Name: RS PRO Desktop Spectrum Analyser 3kHz Bandwidth, 150kHz-3GHz Frequency Range, 5.6 in TFT LCD ISA-730, ISP-730
Brand: RS PRO
SKU: 192057
Price: 1165.04 USD
Availability: InStock



Category Spectrum Analyser Brand RS PRO Condition New

Specifications

Country of Origin	Taiwan
Display Type	TFT LCD
Brand	RS PRO
Height	152mm
Length	296mm
Model	ISA-730, ISP-730
Gross Weight	2.2kg
Width	115.1mm
Bandwidth	3kHz
Maximum Operating Temperature	45°C
Screen Size	5.6 in
Minimum Operating Temperature	5°C
Plug Type	UK
Interface Type	USB, 15-Pin Connector, 9-Pin Connector, RS232
Sweep Modes	Continuous
Maximum Frequency	3GHz
Minimum Frequency	150kHz
Setting Modes	Full Span, Zero Span, Last Span
Markers	Amplitude, Frequency
RF Input	N Connector
Desktop/Handheld	Desktop
RBW (resolution bandwidth) Range	30kHz,100kHz,300kHz,1MHz
Support Interface	USB Device/Host, RS-232C

Key Features

Equipped with a 5.6 inch TFT LCD display with VGA output for clear visualization.
Offers continuous sweep modes with full span, zero span, and last span setting options.
Features amplitude and frequency markers for enhanced signal analysis.
Includes USB, 15-pin, 9-pin connectors and RS232 interface types for versatile connectivity.
Designed for desktop use and supports remote control software for efficient operation.
Incorporates resolution bandwidth range from 30kHz up to 1MHz to suit different measurement needs.
Operates reliably within temperature range of 5°C to 45°C.
Compact form factor with dimensions 296mm length, 152mm height, and 115.1mm width.

Product Description

RS PRO ISA-730, ISP-730 Desktop Spectrum Analyser 3kHz bandwidth offers robust and precise analysis of radio frequency (RF) and wireless signals from 150kHz up to 3GHz.

This Spectrum Analyser features a bright 5.6 inch TFT LCD with VGA output, providing clear visuals of frequency distribution. It supports continuous sweep modes with multiple setting options including full span, zero span, and last span for flexible measurement control. Amplitude and frequency markers enable accurate signal characterization.

Connectivity options include USB device/host, 15-pin, 9-pin connectors, and RS232 interface, making it compatible with a wide range of equipment and remote control software, which is available as a free download. The resolution bandwidth ranges from 30kHz to 1MHz, allowing users to tailor analysis to various signal complexities.

The device is built for desktop use and offers a compact footprint with dimensions of 296mm length, 152mm height, and 115.1mm width. Operating temperature range from 5°C to 45°C ensures stable performance in typical environments. Weighing approximately 2.2kg, the analyser balances portability with stability.

This model is manufactured in Taiwan, Province of China, and complies with numerous international standards including EN 61000 series, RoHS, and EMC directives, demonstrating its adherence to high industry quality and safety norms.

Equipped with 3kHz bandwidth and frequency range of 150kHz to 3GHz. 5.6 inch TFT LCD display with VGA output. Multiple sweep and setting modes for comprehensive signal analysis. Standard interfaces including USB and RS232 for device communication.

Suitable for RF communications, wireless device testing, and education. Compact and desktop design with detailed measurement markers.

Explore RS PRO products for reliable spectrum analysis solutions suitable for industrial, laboratory, and educational environments. EnvMart offers a broad range of measuring and testing instruments to match diverse application needs.
