Epson 24.576MHz XO Oscillator ±50 ppm CMOS 4-Pin Surface Mount Q3309CA40006512

Free Delivery in India | Lowest Global Shipping Charges

Epson 24.576MHz XO Oscillator ±50 ppm CMOS 4-Pin Surface Mount Q3309CA40006512

Name: Epson 24.576MHz XO Oscillator ±50 ppm CMOS 4-Pin Surface Mount Q3309CA40006512
Brand: Epson
SKU: 188915
Price: 8.21 USD
Availability: InStock



Category Crystal Oscillator Brand Epson Condition New

Specifications

Country of Origin	India
Brand	Epson
Height	1.4mm
Length	7mm
Model	Q3309CA40006512
Width	5mm
Series	SG-8002
Maximum Operating Temperature	70°C
Output Frequency	24.576MHz
Package Type	Surface Mount
Minimum Operating Temperature	-20°C
Standards/Approvals	EU RoHS, ISO 14001, ISO9001
Pin Count	4
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	2.7V
Oscillator Type	XO
Output Level	CMOS
Epson, 20MHz XO Oscillator, ±50ppm CMOS, 4-Pin SMD Q3306JA21013401Brand	Epson
AKER, 24.576MHz XO Oscillator, ±50 ppm HCMOS, 4-Pin Surface MountBrand	AKER

Key Features

Operates with a supply voltage range from 2.7V to 5.5V.
Compact ceramic package measuring 7mm length, 5mm width, and 1.4mm height.
Temperature range from -20°C to 70°C ensures reliable operation in diverse environments.
Features 4-pin configuration suitable for surface mounting.
Complies with EU RoHS, ISO 14001, and ISO 9001 standards for quality and environmental responsibility.
Low current consumption suitable for efficient electronic circuit applications.
Part of the SG-8002 series designed with PPL technology for precise high-frequency output.
Ideal for applications requiring stable and accurate timing references.

Product Description

Epson Q3309CA40006512 XO Oscillator is a 24.576MHz frequency surface mount crystal oscillator designed with CMOS output technology and ±50 ppm stability, ideal for various electronics applications requiring precise timing.

This oscillator operates over a supply voltage range of 2.7V to 5.5V, enabling compatibility with a range of low-voltage circuits and power-efficient devices.

Housed in a compact ceramic package measuring 7mm in length, 5mm in width, and 1.4mm in height, the component ensures minimal footprint on printed circuit boards (PCBs), facilitating compact electronic designs.

Operating temperature ranges from -20°C to 70°C enable the oscillator to function reliably in industrial, commercial, and consumer electronics environments. The device features a 4-pin surface mount configuration for easy PCB integration and soldering.

Produced under stringent quality control, the oscillator complies with EU RoHS, ISO 14001 environmental management, and ISO 9001 quality standards, ensuring durability and compliance with industry regulations.

The SG-8002 series technology incorporates PPL mechanisms, providing stable and accurate frequency output for timing and synchronization in communication, automotive electronics, industrial control systems, and other precision electronic equipment.

Operates with supply voltages between 2.7V and 5.5V. Compact 7x5x1.4 mm ceramic case dimensions minimize PCB space usage. Wide operating temperature range from -20°C to 70°C. Stable output frequency of 24.576MHz with ±50 ppm tolerance.

4-pin surface mount design for modern PCB applications. Compliance with EU RoHS and ISO standards ensures environmental and quality adherence. Low power consumption optimizing battery and power management applications.

This Epson XO oscillator is suitable for industrial, telecommunications, embedded systems, data communications, and other applications demanding high-frequency crystal oscillator components for stable and precise timing control.
