Samtec CLM Series Vertical Through Hole PCB Socket, 4-Contact, 2 Row, 1 mm Pitch, 270V, 3.1A Current, Gold CLM-102-02-L-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 270V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 3.1A |
| Model | CLM-102-02-L-D |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Current Rating | 2.8A per pin |
| Series | CLM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Connector System | Board-to-Board |
| Insulator Material | black LCP |
| Operating temp range | -55°C to +125°C |
Key Features
- Constructed with liquid crystal polymer housing material for durability.
- Features low profile dual wipe Tiger Claw gold plated contacts.
- Designed for vertical orientation and through hole mounting on PCBs.
- Operating temperature ranges from -55°C to 125°C ensuring stable performance.
- Suitable for use in electronic, industrial, and manufacturing applications.
- Phosphor bronze contact material provides excellent conductivity and reliability.
- Series CLM socket supports rugged and reliable micro socket connections.
- Gold plated contacts enable corrosion resistance and long life.
Product Description
Samtec CLM Series Vertical Through Hole PCB Socket model CLM-102-02-L-D is a rugged and reliable micro socket designed for board-to-board electrical interconnections. This socket features 4 contacts arranged in 2 rows with a 1 mm pitch and supports current ratings up to 3.1A with a maximum voltage of 270V. It is constructed using black liquid crystal polymer (LCP) as the housing material, which offers mechanical stability and resistance to high temperature environments.
The connector employs a low profile dual wipe Tiger Claw contact design with gold plating to ensure optimal electrical performance and corrosion resistance. Contact material is phosphor bronze, known for its superior conductivity and mechanical robustness. The mounting type is through hole, suited for vertical orientation on printed circuit boards, making it ideal for compact and space-critical designs.
Operating temperature specifications range from -55°C to +125°C, allowing reliable use in harsh industrial, electronic, and manufacturing environments. The CLM series marries durability with precise electrical performance to meet demanding application needs.
Durable liquid crystal polymer housing material enhances mechanical strength. Gold plated phosphor bronze contacts provide excellent conductivity and corrosion resistance. Low profile dual wipe Tiger Claw contact design ensures reliable electrical connections.
Through hole vertical mounting suits dense PCB layouts. Wide operating temperature range from -55°C to +125°C. Designed for board-to-board connector systems supporting 270V and 3.1A currents. Micro socket with rugged build quality for industrial and electronic applications.
Black insulator material offers additional durability in harsh conditions.
This PCB socket is suitable for various electronics manufacturing, industrial automation, and laboratory equipment requiring dependable connectivity. It complies fully with CLM series standards and supports long operational lifetimes due to superior materials and plating techniques.
Explore more high-reliability PCB connectors and sockets at EnvMart to optimize your electronic system designs and manufacturing processes.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this model is 270V.
This socket supports a current rating of 3.1A.
The housing material is liquid crystal polymer (LCP), and the contact material is phosphor bronze with gold plating.
The socket features a 1 mm pitch and has 4 contacts arranged in 2 rows.
It operates within a temperature range of -55°C to +125°C.
This model is designed for through hole mounting on printed circuit boards.
It supports a board-to-board connector system.
The termination type for this model is solder.
The low profile dual wipe Tiger Claw contact design ensures reliable electrical connections and optimal performance.
The country of origin for this socket is India.
This socket is suitable for various electronics manufacturing, industrial automation, and laboratory equipment applications.
The insulator material is black liquid crystal polymer (LCP).
