onsemi General Purpose PNP Transistor, -1.5 A, -80 V, 4-Pin SOT-223 Package BCP53-16T1G

onsemi BCP53-16T1G is a high-performance General Purpose PNP Transistor provided in a 4-pin SOT-223 surface mount package. It is designed for applications requiring a maximum DC collector current of -1.5 A and collector-emitter voltage rating of -80 V. This transistor offers a single configuration and PNP polarity for fluid integration in electronic circuits.

The device is capable of dissipating up to 1.5 W power and operates efficiently across a broad temperature spectrum from -65°C to 150°C, making it suitable for demanding environments in industrial electronics, power supplies, and automotive circuits not conforming to AEC-Q101 automotive standards. With a transition frequency of 50 MHz, it can operate in many moderate-speed switching and amplification tasks.

Its compact dimensions of 7.3 mm height, 6.7 mm length, and 1.75 mm width facilitate space-saving PCB designs. The transistor mounts onto printed circuit boards via its surface mount SOT-223 package, enhancing assembly productivity.

Key electrical characteristics include a maximum collector-base voltage of 100 V and an emitter-base voltage of 5 V, which provide robust voltage handling and improve reliability. Its minimum DC current gain (hFE) is rated at 100, assisting in effective amplification performance.

This product is a member of the BCP53 series and does not meet automotive standards (No AEC-Q101 certification). Typical use cases include industrial control systems, power regulation modules, and signal processing circuits in electronics manufacturing.

This transistor features single configuration with PNP polarity for versatile circuit applications. Maximum power dissipation is rated at 1.5 watts for reliable operation. It supports a transition frequency of 50 MHz, suitable for moderate frequency switching tasks.

Operating temperature range spans from -65°C to 150°C, providing durability in harsh environments. Compact physical dimensions include a height of 7.3 mm, length of 6.7 mm, and width of 1.75 mm. Standard surface mounting type ensures easy PCB assembly with SOT-223 package footprint.

Maximum collector-base voltage is 100 V and emitter-base voltage is 5 V for robust performance margins. Designed primarily for general-purpose applications, ideal for industrial and electronic component use cases. Discover more specialized electronic components and Bipolar Transistors in EnvMart's comprehensive catalog to optimize your next project.
